1T 8M Telescopic Marine Deck Crane PLC Industrial Control
1T8M Telescopic Boom Marine Crane PLC industrial control device
Product description
OUCO marine cranes are specially designed to lift and wash cargo from ships.
A safe and controllable system significantly reduces maintenance costs.
Hydraulic lift cylinders, cables and pulleys are all built into the crane mast to give the crane a smoother appearance.
The biggest advantage of this crane is that it takes up less space and is more efficient, and all equipment is hydraulically driven.
Fully automatic PLC industrial control device.
Main Features and advantages
1. The variable speed winch of OUCO marine crane can be automatically adjusted to the highest speed suitable for the load.
2. The crane is equipped with various safety protection devices, such as on-hook limiter, overload limiter and emergency stop button.
3. More complex welding technology is adopted to ensure the high strength of the crane arm and reduce maintenance costs in the later period.
4. Standalone unit with integrated hydraulic power unit.
5. All operations are managed by fail-safe brakes.
Technical Specification
| SWL | 1T@8M |
| Working Radius | 1~8m |
| Hoisting Speed | 0~15m/min |
| Hoisting Height | 25m |
| Slewing Speed | ~0.8r/min |
| Slewing Angle | 360° |
| Luffing Time | ~25s |
| Extension Time | ~30s |
| Tirm | ≤2° |
| Heel | ≤5° |
| Motor Type | Y160M-4-H |
| Motor Power | 11KW |
| Motor Speed | 1450r/min |
| Power source | AC440V, 60Hz, 3P/AC380V, 50Hz, 3P |
| Protect Class | IP44 |
| Insulate Class | F |
| Working Type | S1 |
| Advised Oil Fow | 25L/min |
| Design Temperature | -10°~+45° |
General Arrangement
Detailed Images
