Fiber Optic Ceramic Frit Banded , Heat Shrinkable Tube Protection Sleeve
Ceramic Fiber Frit Banded Heat Shrinkable Tube
Applications:
Manufactured by cross-linked polyolefin, ceramic rod, and hot fusion tubing. Specially designed to rebuild the coating of fiber, providing mechanical strength at the fusion joint area and keeping optical transmission properties.
Characteristics:
Moisture resistant and environmental protection
Simple operation, avoid any damages to optical fiber during installation.
Operating temperature range:
Operating temperature: 45℃-100 ℃/55℃-130 ℃
Minimum shrink temperature : 80℃
Minimum fully recovery temperature: 120℃nsionsTechnic
|
Part Number |
Item Number |
SleeveLength(L)(mm) | Hotmelt Tube(D)(mm) | Ceramic rods(d) | |
| Width(mm) | Height (mm) | ||||
|
FOSP-4RD Single ceramic |
38132235 | 42±0.8 | 1.3*2.2 | 3.0±0.1 | 1.5±0.1 |
|
FOSP-4RS Dual ceramic |
46132240 | 42±0.8 | 1.3*2.2 | 3.0±0.1 | 1.5±0.1 |
|
FOSP-6RD Single ceramic |
38182843 | 42±0.8 | 1.8*2.8 | 3.0±0.1 | 1.5±0.1 |
|
FOSP-6RS Dual ceramic |
45182846 | 42±0.8 | 1.8*2.8 | 3.0±0.1 | 1.5±0.1 |
|
FOSP-8RD Single ceramic |
48243455 | 42±0.8 | 2.4*3.4 | 4.0±0.1 | 2.0±0.1 |
|
FOSP-8RS Dual ceramic |
55243458 | 42±0.8 | 2.4*3.4 | 4.0±0.1 | 2.0±0.1 |
|
FOSP-12RD Single ceramic |
49243558 | 42±0.8 | 2.4*3.5 | 4.0±0.1 | 2.0±0.1 |
|
FOSP-12RS Dual ceramic |
58243560 | 42±0.8 | 2.4*3.5 | 4.0±0.1 |
2.0±0.1 |
