B20 Size 600 - 850 μm Ceramic Bead Blasting 3.85g/cm3 Density 700HV Hardness
B20 Size 600-850 μm Ceramic Bead Blasting in 12.5 Kgs Barrel +paper carton
Description of Ceramic beads blasting media
Ceramic blasting media also called ceramic micro beads, ZrO2 62-66%, with good roundness and good elasticity, no dirt adhesion and easy to clean after sandblasting, suitable for
surface finish and micro blast material removal in medical devices industries.
Ceramic beads micro-abrasive blasting is a cost-effective, eco friendly surface treatment solution in medical applications.
Specification of Ceramic beads blasting media
| ZrO2 | SiO2 | Al2O3 | Other |
| 60-66%, | 25-30% max. | 7-13% max. | 5-8% |
| Color | Bulk Density | True Specific Density | Vickers Hardness |
| White | 2.3g/cm3 | 3.85g/cm3 | 700 HV |
Particle size range:
B20:0.600-0.850mm B80:0.180-0.250mm
B30:0.425-0.600mm B120:0.063-0.125mm
B40:0.250-0.425mm B170:0.045-0.090mm
B60:0.125-0.250mm B205:0.000-0.063mm
Special specifications can be customized.
Features of Ceramic beads blasting media
1. High hardness, long life and good elasticity
The zirconia sand ceramic beads has high hardness, vickers 700HV.It ensures that the ceramic beads can be shot peened for high-strength and ultra-high-strength structural parts. The small deformation ensures that the shape of the projectile does not change during impact.
2. Recyclable and improving efficiency
Ceramic bead blasting media has long service life and high cost performance: The life of ceramic bead is more than 20 times that of glass beads.
Ceramic beads not easy to be broken, and low wear, it can effectively reduce the materials replacement times and reduce the cost of workers to improve efficiency.
Application of Ceramic beads blasting media
Ceramic beads micro blasting is used on a variety of materials like:
· Titanium
· Stainless Steel
· Ceramic
· Nitinol
· Aluminum
To restore surface finish, clean implantable devices.
The ceramic bead micro blast in a medical device cleans the oxide and removes residue from the side walls of the stent and removes the heel burrs on the needle.
Micro blast Cleaning
· Heart valves
· Catheters
· Defibrillator leads
Precision Deburring
· Titanium bone screws
· Needles
· Endoscopy tools
Applicable equipment of Ceramic beads blasting media
Manual sandblasting machine
Automatic sandblasting machine
Open type sandblasting machine
Sandblasting machine room
If you're looking for ceramic beads, pls contact us to get advisory service, best price, more details and sample, etc.
