Revolutionize Your Metal Production with Induction Melting Furnace 250KW
Induction Melting Foundry Furnace: A Revolutionary Way to Melt Metals
Are you tired of traditional methods of melting metals that take up a lot of time, energy, and resources? Look no further, because Lanshuo's Induction Melting Foundry Furnace is here to provide you with a faster, more efficient, and energy-saving solution.
Product Description
The Lanshuo Induction Melting Foundry Furnace, also known as the KGPS-200KG, is a state-of-the-art induction heating machine specifically designed for melting various types of metals such as copper, aluminum, iron, steel, bronze, and brass. It is an essential tool for industries involved in continuous casting, die casting, and investment casting.
Technical Parameters:
| Article | Rated capacity | Rated power | Transformer capacity | Input voltage | Frequency -MF | -MF Voltage | Voltage-DC | Current-DC |
| KGPS-200KW | 250KG/H | 200KW | 250KVA | 380V 50-60HZ | 2000HZ | 750V phase | 500V phase | 400A phase |
| Nominal temperature | Fusion time | Closed cooling tower (circulating water) | KGPS Fast Medium Frequency Power Supply | Oven | Reducer | water cooled cable | crucible mold | Specification information |
| 1800℃ | 20-45min | LSN-20T/H | 1 set | one/two | RZS231 1 set | 240mm² *2 | 1 | 1 |
Features of medium frequency induction melting furnace:
1. High melting rate.
2. Good-quality molten steel, high casting product yield.
3. High power factor. During the machine's operation, the power factor can reach over 97%.
4. No harm to the power gird.
5. Low power consumption, saving over 10% energy.
6. High start-up success rate. Under any load, the start-up success rate is 100%.
7. The main control panel adopts plug-in connector, easier maintenance.
8. Simple to install. Installation can be done by unprofessional workers very easily.
9. The machine adopts series thyistor, making the SCR damage rate to a minimum.
Application:
(1) iron, pig iron, cast iron;
(2) steel, stainless steel, cast steel, carbon steel and bearing steel;
(3) gold, silver, platinum;
(4) copper, brass, bronze;
(5) aluminum, aluminum alloy;
(6) zinc, lead, tin, magnesium, nickel, titanium.
Packing and Shipping:
2. Put it into a standard exporting plywood or wooden case;
3. Put foam around it for shockproof;
4. Fasten the case with nails.
The Induction Melting Furnace is packaged in a sturdy wooden crate to ensure safe transportation. The furnace is securely fastened and protected with foam padding to prevent any damage during shipping.
For international shipping, the crate is then placed on a pallet and wrapped with shrink wrap for added protection.
Upon arrival, the crate is carefully unloaded and inspected for any signs of damage. Any necessary precautions will be taken to ensure the furnace is delivered in perfect condition.
Our shipping team is well-trained and experienced in handling delicate equipment, ensuring that your Induction Melting Furnace arrives safely and on time.
