100KW Induction Heating Machine for Metal Metallurgy- Iron Rods, Steel Plates and Other Metals Heat Treatment
Price:
4000USD-6000USD
MOQ:
1 SET
Delivery Time:
3-5 WORKING DAYS
Brand:
ZHENGZHOU LANSHUO
Product Description
|
Parameter |
Working voltage | 380V/50-60HZ |
| Max input power | 100KW | |
| DC voltage | 500V | |
| DC current | 150A | |
| Input power control switch | 3*200A | |
| Enter the power cord | 70mm² Copper wire | |
| Equipment ground wire | 1.5mm² Soft copper wire | |
| The heating frequency | 18-25KHZ | |
| Air switch | 3*150A | |
| Ground wire | 1.5mm² | |
| The water pressure | 0.15-0.2MPa | |
| Weight(after packing) | 200KG | |
| Dimension(after packing) | 770*600*1480mm(Host) 1000*620*700mm(Auxiliar-y engine) | |
|
Cooling water installation |
Control cabinet water interface quantity |
Water inlet:one Outlet:one |
| The number of auxiliary water outlets |
Water inlet:one Outlet:one |
|
| The pipe specifications |
Incoming water pipe: internal diameter 25mm Equipment outlet pipe: internal diameter 25mm |
|
The name of accessories |
main plate | one |
| Driver board | one | |
| Module | one | |
| The circular | one | |
| panel | one | |
| Delay board | one | |
| Potentiometer | one | |
| Control transformer | one | |
| absorb the capacitance | one | |
| IGBT water box | one | |
| Filter capacitance | one | |
| Three-phase bridge water box | one | |
| Hydraulic pressure gauge | one | |
| ammeter | one | |
| 380V small plate | one |
Pictures:
CE:
