Lightweight Aluminum Structure Conveyor Belt Joint Machine, Conveyor Belt Jointing Machine
Lightweight Aluminum Structure Conveyor Belt Joint Machine, Conveyor Belt Jointing Machine
The conveyor belt joint machine is mainly used to joint the fractured conveyor belt or joint the short conveyors to longer one. Can be used on fabric core conveyor belt, steel wire conveyor belt, PVC belt, PU belt etc.
The host machine body consists of 8groups beam, 4pcs heating plate, 4 water pressure blader,
Machine specification:
| Model |
Belt Width (mm) |
Power(kw) |
Dimensions (L*W*H mm) |
Weight(kg) | Single Piece Weight(kg) |
| ZLJ-650*830 | 650 | 9.5 | 1370*830*630 | 430 | 45 |
| ZLJ-650*1000 | 10.8 | 1370*1000*630 | 500 | 66 | |
| ZLJ-800*830 | 800 | 11.2 | 1520*830*630 | 535 | 70 |
| ZLJ-800*1000 | 13.5 | 1520*1000*630 | 575 | 79 | |
| ZLJ-1000*830 | 1000 | 14.1 | 1720*830*630 | 595 | 82 |
| ZLJ-1000*1000 | 15.7 | 1720*1000*630 | 620 | 95 | |
| ZLJ-1200*830 | 1200 | 16.5 | 1920*830*710 | 800 | 96 |
| ZLJ-1200*1000 | 17.2 | 1920*1000*710 | 870 | 113 | |
| ZLJ-1400*830 | 1400 | 18.6 | 1930*830*760 | 930 | 107 |
| ZLJ-1400*1000 | 20.7 | 2120*1000*760 | 1180 | 132 | |
| ZLJ-1600*830 | 1600 | 21.5 | 2320*830*800 | 1270 | 120 |
| ZLJ-1600*1000 | 22.3 | 2320*1000*800 | 1460 | 146 | |
| ZLJ-1800*830 | 1800 | 23.3 | 2520*830*850 | 1380 | 137 |
| ZLJ-1800*1000 | 25.6 | 2520*1000*850 | 1650 | 164 | |
| ZLJ-2000*830 | 2000 | 27.2 | 2720*830*950 | 1760 | 154 |
| ZLJ-2000*1000 | 30 | 2720*1000*950 | 1860 | 182 | |
| ZLJ-2200*830 | 2200 | 29.2 | 2920*830*950 | 1860 | 165 |
| ZLJ-2200*1000 | 34.1 | 2920*1000*950 | 1970 | 198 | |
| ZLJ-2200*1450 | 49 | 2920*1450*950 | 2090 | 90 |
Separated heating plate makes it easier to carry and installation.
Much more safer design tighting bolts:
Heating plates:
Our workshop:
We can design & make the machines according to your requirements!
