Efficient Conveyor Belt Splicing Machine Vulcanizing Press 1000mm*300mm, Belt-edge vulcanizing press repair machine

XL strip vulcanizing repair machine, also known as the belt-edge repair vulcanizing machine, is mainly applied to repair the long-distance damage, longitudinal piercing as well as edge damages on the conveyor belt on site. It’s time-saving, efficient and easy operated. Main models are as following: XL-1000*300mm,XL-1200*830mm,XL-1400*830mm,XL-1600*8300mm,XL-1800*830mm or as customized.

This Belt-edge vulcanizing press repair machine equipment with 4 universal wheels, easy to move and operate.

Machine specification:

Belt-edge vulcanizing press repair is mainly applied to industries for splicing and repairing for conveyor belts such as metallurgy, mine, power plant, port, dock, construction material cement, chemical industry , tobacco ,and food automatic line field.

Features:

1.Machine Maximum size: from 300MM-2000MM,Or according the customer
2.Voltage: 220V 380V 415V 660V 50HZ;
3.Fast Cooling time: 15 minutes (from 145 degrees down to 70 degrees or less);
4.Time for temperature raise (from normal temperature to vulcanizing temperature) no more than 25 minutes;
5.The temperature difference of sulfide surface: ±2°c.
6.Temperature adjustment range: 0~300°c.
7.Vulcanizing pressure: 0~2.5 MPa (details refer to users' specifications and factory markings);
8.Time of heat preservation for vulcanizing could be adjusted according to thickness of the rubber belts;
9. Splicing length of rubber conveyor belt for vulcanizing jointing could be connected together by single or several pieces if necessary;
10. rubber conveyor belt as well as tension in kilogram required for vulcanizing jointing when ordering products.
11. Users could order spare electric pumps additionally according to the requirements.
