20MPa 250KN Metal C Frame 100T Hydraulic Bench Press

Price Negotiable
MOQ: 1 sets
Delivery Time: 3 weeks
Brand: SMART CNC
Product Description

Y41 Single Column Powder Compacting Hydraulic Bench Press 25-100 ton

Y41 C Frame 25 ton hydraulic press with single column
One kind of multifunctional medium-small hydraulic press.

It can be used in bearings and moulding, also suitable for bearings and sleeves.

At the same time,the machine can complete the technology function of bending, shelling of plate material parts, stretching of simple parts, pressing powder, plastic products, etc.


It is mainly suitable for metal sheet curveting, flattening, stretching, stamping, shaft parts coupling, powder and plastic forming. This product is applied in the machine tool, automotive, motor vehicles, air-conditioned shell, mechanical bearings, powder metallurgy, and plastic industry.



No
Items
Unit
Y41-25T
1
Nominal force
KN
250
2
Max open height
mm
560
3
System working pressure
MPa
20
4
Throat depth
mm
200
5
Slide stroke
mm
300
6
Down

mm/s
60
7
Slide speed Return

mm/s
60
8
Work
mm/s
8-12
9
Worktable size
mm
500*400
10
Dimension
mm
1100*650*2050
11
Motor power
KW
3
