Used Fence Cargo Truck Chassis Shacman L5000 4×2 DRIVE MODE 240hp 6.8m Long Stake EURO 6 Truck
Used Fence Cargo Truck Chassis Shacman L5000 4×2 DRIVE MODE 240hp 6.8m Long Stake EURO 6 Truck
Description:
With sufficient power and good quality, it is your good transportation partner. High Performance: Built for heavy-duty work. Fuel Efficient: Maximize your investment. For used truck we do such working: Refurbish cabin, Refurbish Engine ＆ Gearbox, New Seats, New Box, New Tires, New Oil Tanker ＆ Water Tankers, New all the Electric circuit, oil circuit, air circuit.
Service we can provide:
yutong bus, higer bus, kinglong bus, golden dragon bus, sunlong bus, etc. Also can provide used trucks like howo dump trucks, tractor trucks, concrete mixer trucks, tanker trucks, and other special purpose trucks, etc.Used Fence Cargo Truck
Except the products, we can also provide sepcial USED VEHICLES AND USED MACHIENRY export business. We warmly welcome all customers and friends who need our service, and happy to build long-term relationship with you.Used Fence Cargo Truck
| Product | Shacman Used Box Cargo Trucks | Model | L5000 | |
| Drive type | 4x2, left-hand drive | |||
| Dimension | Overall dimension (mm) L*W*H | 8995*2550*3960 | ||
| Box inside dimension (mm) L*W*H | 6800*2450 | |||
| Bucket cubage (m 3 ) | ||||
| Thickness of box (mm) | ||||
| Wheel base (mm) | 3625+1350 | |||
| Overhang (front/rear, mm) | 1935/1860 | |||
| Wheel tread (frong/rear, mm) | 2022/1830 | |||
| Approach/departure angle (°) | 19/26 | |||
| Weight | Gross vehicle weight(kg) | 7815 | ||
| Pay load (kg) | 9900 | |||
| Actual load (kg) | > 9900 | |||
| Overall weight (kg) | 18000 | |||
| Box lifting type | Front hydraulic lifting | |||
| Max. speed (km/h) | 75 | |||
| Chassis | Number of axles | 3 | ||
| Tire | 12.00R20, radial tire | |||
| Number of tires | 10+1 | |||
| Cab | Model | HW70 standard, two seats, air conditioner, no bed |
||
| Engine | Model | WD615.47 | ||
| Displacement (ml) | 51300 | |||
| Rated power (hp/rpm) | 371/2200 | |||
| Emission standard | Euro 6 | |||
| Fuel tank capacity (L) | 300 | |||
| Clutch | Model | single, dry spring | ||
| Gear box | Model | HW19710 | ||
| Type | manual | |||
| Gears | 10 forward, 2 reverse | |||
| PTO | included | |||
| Steering | Model | ZF 8098 | ||
| Type | integral power steering | |||
| Front axle | Model | HF9 hub, 6500 kgs | ||
| Rear axle | Model | HC16, 2x11,500 kgs | ||
| Braking system | Type | Air brake | ||
| ABS | Optional | |||
