Gold To Gold IP54 300rpm Flexible Capsule Slip Rings
Gold to gold 24 rings of signal slip ring
CENO's capsule slip rings have flexible spec options to fulfill the various and complex requirement of systems.Ring number are range from 2 rings up to 200 rings.Power and signal are easily to be integrated into one slip rings under our years of proven technique.Outstanding signal types are Ethernet,Canbus,Profibus,RS,HDMI,HD-SDI,USB and so on. Typical outside diameters including 5.5mm,12.4mm,22mm.
Specification
| ECN000-07P3-29S | |
| Rings | 24*signal |
| Voltage | 0~220VAC/VDC |
| Electrical noise | ≤35mΩ |
| Dielectric strength | ≥500V@50Hz |
| Insulation resistance | ≥50MΩ@500VDC |
| Operating speed | 0-300rpm |
| Contact material | Gold to gold |
| Housing material | Aluminium alloy |
| IP protection grade | IP54 |
Features
- Compact size.
- Adopt military grade surface treatment,gold to gold contacts
- Transmit data and analog signal,compatible with bus protocol
Applications
- Radar system
- Military equipment
- Medical equipment
Optional
- Circuit number
- Current rating
- Signal type
- IP protection grade
Why with CENO
CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
Certification
ISO9001,CE,RoHS,UL,Explosion-proof
CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.
Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
