ACN-02P-14S IP54 140mm 60rpm Capsule Slip Ring
Compact size, 5.5mm~25mm are available,ACN-02P-14S
This is capsule slip ring with compact size ,it is designed for high definition video surveillance or serial communication application.Stable data transmission,no packet loss ,low return loss,low error rate,super high SNR.Ring number are range from 2 rings up to 100 rings.power and signal are easily to be integrated into one slip ring,outstanding signal types including Ethernet,canbus,profibus,RS,HDMI,HD-SDI,USB and so on. Typical outside diameter is 5.5mm,12.4mm,22mm in these series.
Specification
| ACN-02P-14S | |
| Current | 2*4A,14*Signal |
| Voltage | 0~240VAC/VDC |
| Electrical noise | ≤35mΩ(50rpm) |
| Dielectric strength | ≥500V@50Hz(signal) |
| Insulation resistance | ≥100MΩ@500VDC(signal) |
| Operating speed | 0-60 rpm |
| Contact material | precious metals |
| Operating temperature | -30~+60°C |
| IP protection grade | IP54 |
| Housing material | Aluminum alloy |
Features
- Compact size, 5.5mm~25mm are available
- Adopt military grade surface treatment,gold to gold contact
- Low contact resistance,low electrical noise,low torque and smooth rotation
Applications
- Radar antenna
- Military equipment
- Mechanical arm
- Medical equipment
Optional
- Signal type
- Circuit number
- Current rating
- Connector type
- IP protection grade
Why with CENO
CENO is one technologically company in slip ring field who engages research and development,manufacturing and sales.We have advanced equipment and high precision test instruments to ensure products quality and reliable performance.Facility area covers 3000 square meters and located in Shenzhen China.
Certification
ISO9001,CE,RoHS,UL,Explosion-proof
CENO Advantage
Member in engineering team have more than 10 years experience in slip ring's field.Operators work on critical procedure are all qualified by internal training.
Service CENO provides
24 hours,7days consultant service.
Mass and customized production.
Solution offerring for 360° rotation system.
Welcome to consult us with your requests for any 360° rotation system.We will provide one stop service to you timely respond your inquiries.
