High Yellowing Resistance Body Safe Silicone Rubber For Patients Health
High Yellowing Resistance Liquid Silicone Rubber For Medical Grade Fantastic Durability For Patients' Health
Description
Our 6250-50YH liquid silicone rubber is a two-component material, and the silicone rubber includes Part A base silicone and Part B curing agent. The Part A base silicone and Part B curing agent can cure at room temperature by an addition reaction, it can be heating during the action, the higher temperature, the faster curing. All LSR are platinum cured (vulcanized) materials which are mixed in a 1: 1 ratio by weight.
Typical Properties
|
RH 6250-50YH |
|
|
Appearance |
translucent |
|
Viscosity(Ma.s) |
1600000-2200000 |
|
Density (g/cm3) |
1.12 ± 0.02 |
|
Shore A Hardness(A) |
50 ± 3 |
|
Tensile Strength(MPa) |
≥ 8.0 |
|
Elongation at break(%) |
≥ 550 |
|
Tear Strength(KN / m) |
≥ 25 |
|
Linear Shrinkage(%) |
≤ 0.1 |
|
Tensile set (%) |
≥ 1.7 |
|
Rebound (%) |
≥ 50 |
|
Compression set((22 hrs at 175℃) % |
≤ 35 |
These figures are for reference only, please contact us for details.
The mixing ratio of components A: B = 1: 1.
Vulcanization: 150 °C / 5 min
Instructions
Here is a look at the LSR molding process:
1. LSR A + B components typically come in a 5-gallon pail or 55-gallon drum. A process controlled pumping kit presses down on the buckets to force the material into the static mixer and feed into the injection unit.
2. Then, streams of pigment can be added and controlled. In the injection, press material will be mixed together additionally with a screw and pushed forward to create a “shot” of material, or the amount needed to fill the mold.
3. After the material is injected into the mold, it will then stay clamped together to cure the LSR. Then, either an operator or a robot will remove the cured product from the mold
Why choose RUI-HE?
- difficult large parts are our specialty
- dual hardness parts
- rubber-to-metal bonding
- short run capability
- three-shift operation
- experienced workforce
- a wide range of rubber compounds
- multiple packaging options for finished parts
Certificate
LSR 6250-50YH® Liquid silicone rubber obtained the following test certificate: RoHS, FDA, REACH, PAHS, ISO9001:2016, etc.
Packing & Storage
Available in 20kg pails or 200kg drums.
Store in a cool, dry place out of direct sunlight, use it within 12 months from the day of manufacture.
Notice
This product cannot be contacted with compounds containing N, P, S to avoid affecting the catalytic effect of platinum.
If you need to know the prices of our silicone rubbers, please contact us. We do not provide prices on the website because prices fluctuate for many reasons.
