Plastic Sheet Extrusion Machine High Efficiency 0.2 - 2mm Sheet Thickness
PE PP PS Sheet Extrusion Line High Efficiency 0.2 - 2mm Sheet Thickness
Plastic Sheet Extrusion Machine High Efficiency 0.2 - 2mm Sheet Thickness
Introduction :
This line is specially used for producing PP/PE single layer or multi-layer sheet or plate, suitable in the fields of packaging, stationery, chemicals, construction, household appliances and so on.
Usual sheet width:700, 900, 1020, 1200, 1300, 1400, 1500, 1700, 1800, 2100, 2200mm
Usual sheet thickness:0.5-2mm, 1.5-10mm,
Machine list
1. SJ-120/35 single screw extruder 1 set
2. SJ-120 Auto changer 1 set
3. SJT-1500 PP sheet molds (2-5mm, 6-8mm) 1 set T die, 2 sets core die
4. SDX-1500 Vacuum cooling calibration 2 sets
5. SJ-1500 12-roller haul-off machine 1 set
6. SJ-1500 Hot air cycling system 1 set
7. SJ-1500 Directional cooling system 1 set
8. SJ-1500 6-roller haul-off machine 1 set
9. SJ-1500 Cutting Machine 1 set
10. SJ-1500 Board system 1 set
11. HMC - Ι control system 1 set
Technical parameters :
| Extruder Model | LMSB-90/33 | LMSB-100/33 | LMSB-120/33 | LMS-100/65 | LMSB-120/65 |
| Sheet Width | 300-610mm | 500-950mm | 1000-1500mm | 500-950mm | 1000-1500mm |
| Sheet Thickness | 0.15-1.4mm | 0.15-1.4mm | 0.15-2mm | 0.25-1.4mm | 0.25-1.4mm |
| Driving Motor | 75KW | 90KW | 132KW | 90KW,75KW | 132KW, 65KW |
| Line Speed | 25m/min | 25m/min | 28m/min | 28m/min | 28m/min |
| Capacity | 180kg/h | 300kg/h | 550kg/h | 450kg/h | 650kg/h |
