2Ton/H Pet Food Snacks Usage Extrusion Machine/Twin Screw Extruder

Product Description SR-90 Pet food 2TON/H extruder machine is suitable to make dry pet food with various sizes and shapes, capacity can reach 2ton/hr.

Features:

Dog/Cat/Fish feed pellet machine focuses on the production of feeds for animals with a high emotional value but low economic usefulness, apart from the aspect of breeding.

A large number of pet food / fish feed with different sizes and shapes products are made by extrusion.

Various recipes are supplied.

Turnkey project provided, from raw materials to packing procedures, fully continuous and automatic.

Fish feed pellet machine is fully made of stainless steel 304, conforming to food grade.

How about the classification ?

• Cereal puffing machine: mainly used for puffed corn, rice and corn

• Flour extruder: it is mainly used in puffed white wheat flour, which is also known as crispy machine

• Soybean extrusion machine, its mainly for expanded soybean , different from the grains puffing machine, soybean extrusion machine contains degreasing device based on soybean oil content

• Feed extrusion machine: are mainly used for extrusion of fish, shrimp, pet food, and other special cultivation with pellet feed production.

♦ Single screw type feed extrusion machine. mainly used for dog treats, can also be used as the pretreatment of the raw material of a vegetable and drinking alcohol production

♦ Twin-screw type feed extrusion machine, mainly used in high-grade aquatic products, pet food production and especially the processing of high viscosity materials

What Function of the twin screw extruder is laudable?

It is widely used in food, feed and industrial field due to an extruder‘s functional diversity, on the extruder (dry, wet, single or twin screw) mechanical structure basis, Qidong would like to introduce one or a set of functions of that in the food or feed processing :

♣Unifying and coacervation : during the extrusion process, food or feed ingredients can be closely integrated and agglomerate into discrete pieces.

♣ Outgassing: food or feed ingredients containing tiny bubbles will be removed in the process .

♣ Dehydration: the water content based on the original will lose 4-7% by the expanded process in general food or feed

♣ Expansion effect: extrusion machine operating condition and configuration can obviously affect the pet feed and aquatic feed porosities (such as heavy or buoyancy)

♣ Gelatination: the cooking during extruding can make the starch (from various sources, such as tubers or grain pasting) in the food or pet food gelatinized by more than 90%

♣ Grinding effect: raw materials can be grinding to a certain extent in the extruder in the food or feed processing

♣ Homogenizing effect: the homogenization effect of the extrusion machine can change not attractive raw material structure to a more acceptable form

♣ Mixing: in the puffing process, by choose a screw from a wide variety,the level and amount of mixing result can be expected

♣ Pasteur type sterilization and sterilization: in the food or feed puffing process, raw materials are deeply sterilized

Any advantages compared with other similar machinery?

1) Modem design with regularly upgrade,compact structure along with multiple function, high production efficiency

2)Reliable, durable, low failure rate, convenient operation and maintenance

3)Simple and convenient use, smooth transmission, low noise

4)Main part is made of special alloy material after heat treatment and, long service life , low the production cost

5)integrated with steam heating system ,high mixing rate and cooking level,dry and wet extrusion mold available

6)Screw design with a strong self-cleaning function, screw groove can realise self-purify, need no stop for cleaning when change of formulation , screw with strong pumping function, feeding faster than ever, stable product inner quality

7)Screw discharging mouth adopts modular design, easy to adjust, the adjusting price is affordable

8)equipped with automatic mixing,dosing,batching,feeding and packing system

9)Independent cutting device connected with the extruder body .convenient, quick, variable cutting speed , easily adjust the cutting knife and clearance between the template

10) stability more than 2 hours in water for floating fish feed pellet

What matters should the owners be facing after long period of usage?

1> bearing can be worn on different grade . need to adjust bearing clearance

2> steam flow back into the feeder, cause the clogging in feeder

3> Air-flow extruder and other ring or flat die pellet mill machine without pre-conditioner get stuck frequently

4> different materials require for different pressure, temperature and screw configuration settings, screw should make a corresponding adjustment
