Siemens Motor Control Pet Food Extruder Machine For Dog Cat 600kg/Hr
Siemens Motor Control Dry Pet Dog/Cat Food Making Extruder Machine
Pet Food Machine Introduction:
Pet Food extruder machine are the all-automatic and food grade processing line. You can make any shape of the pet food according to different market requirements.
In order to increase the protein and other nutrients for our pet,Automatic dry dog pet food machine/processing line use meat powder,grains,beans and vegetables as raw materials to produce pet food with new shape, unique taste to let them live healthier.
1, Materials for dog/cat/fish food:
wheat/ corn flour, fish meal, born powder, animal oil
2, Final food : different shapes and sizes of dog food,cat food,shrimp feed,fish feed,poultry feed
3, Capacity: 150kg/h, 250kg/h, 500-600kg/h,1000kg/h
4,Consumption: Low electricity and labor consumption
5, Design: With flexible design based on the client's demands, we provide turn key project.
6, Grade: SUS201,SUS304
|
Name
|
Description of pet food Extrusion Production Line
|
|
Raw material
|
Corn flour,wheat flour, soy meal, bone powder, fish meal and some other agents.
|
|
Basic Recipe
|
Grist powder, minerals, water etc
|
|
Processing Flow
|
mixing system; Extrusion System; Drying system; cooling system; packing system
|
|
Final products
|
dog food, pet food with Variety shapes are available by adjustable the moulds on the extruder.
|
Standard Configurations for Siemens Motor Control Dry Pet Dog/Cat Food Making Extruder Machine
| Motor | WEG, Brazile, or Siemens, Germany |
| Electric Parts | ABB, Switzerland or Schneider, France |
| PLC & Touch Screen | Siemens, Germany |
| Bearings | NSK, Japan |
| Controller | PLC & Touch Screen controls whole line, not one or two equipment |
| Protector | 3 kinds of protector: overload, overcurrent and overheat. Control cabinet is 24V safe voltage |
| Materials | Cover body, mesh belt and parts touching with products are made by stainless steel 304 |
Technical parameter of the pet production line :
| Model | Capacity | Power | Dimension |
| SR-65 | 120-150kg/hr | 80kw | 18 x 5 x 3m |
| SR-70 | 200-300kg/hr | 90kw | 20 x 5 x 3m |
| SR-85 | 500-600kg/hr | 150kw | 30 x 5 x 4m |
| SR-90 | 800-1000kg/hr | 200kw | 35 x 5 x 5m |
| SR-95 | 2000kg/hr | 250kw | 40 x 10 x 16m |
| SR-120 | 3000kg/hr | 350kw | 50 x 10 x 20m |
| SR-135 | 5000kg/hr | 450kw | 60 x 10 x 24m |
The flow chart will be showing below :
Samples:
A. Finished time
The production line will be finished in 25-40 days after confirmation.
B. Payment Term
30% is paid by T/T as the down payment, 70% is paid by T/T or L/C before shipment.
C. Delivery Time
When the machines are finished, we will invite you to our factory for testing machine.
then we will arrange the worker to load container promptly after all corresponding inspection issues finished.
RFQ:
Videos link for pet food production line:
Any interest, please be free to contact us!
