High Pressure Tolerance Hydraulic Piston Motor MS08 780cc 170rpm For Forest Felling Machine
Poclain Hydraulic Piston Motor MS08 780cc 170rpm for Forest Felling Machine
Poclain : MS08/MSE08 radial piston hydraulic motor
Helm Tower brand MS/MSE Series Hydraulic Motor is one kind of low speed high torque radial piston motor with modular design, multi-disc brake (holding brake) ,high pressure tolerance, smooth running even at very low speeds, available with different valves.
The MS/MSE series motor can be added all kinds of hydraulic valves, mechanical brake, wheel output shaft and other components, motor can make a double displacement, multi-functions collocation can meet the needs of users in various fields.
|
Type Displacement |
MS08-8 | MS08-9 | MS08-0 | MS08-1 | MS08-2 | |||||
| Full/Semi | Full/Semi | Full/Semi | Full/Semi | Full/Semi | ||||||
| Displacement(ml/r) | 627 | 313 | 702 | 351 | 780 | 390 | 857 | 428 | 934 | 467 |
| Max power(kw) | 36 | 24 | 36 | 24 | 36 | 24 | 36 | 24 | 36 | 24 |
|
Pressure discrepancy 10MPa Torque (N.m) |
937 | 459 | 1049 | 514 | 1166 | 571 | 1281 | 628 | 1396 | 684 |
| Rated torque(N.m) | 2343 | 2623 | 2914 | 3202 | 3490 | |||||
| Rated pressure(MPa) | 25 | 25 | 25 | 25 | 25 | |||||
| Max pressure(MPa) | 40 | 40 | 40 | 35 | 35 | |||||
| Rated speed(r/min) | 70 | 70 | 70 | 65 | 65 | |||||
| Speed range(r/min) | 0-170 | 0-170 | 0-170 | 0-155 | 0-140 | |||||
Construction Machinery: Beam Carrier/Hoisting Machine, Cement Concrete Mixing Station, Cinder,Belt Conveyor.
Farming Machinery:Spray Machine.
Mining Machinery:Mini Road Header, Scraper,Heavy Duty Handling Car,Coal Mine Drill.
Marine Machinery: Marine Deck Crane.
MS08 Connection Dimension
High precision testing facilities and experienced inspectors.
