Insulated Hard Coated Low Emissivity Glass For Buildings
Insulated Glass with FGB Series Hard Coated Low-E for Buildings for different Climates
Description:
Hard coated Low-E glass is made by coating the glass with a thin metallic oxide layer at the end of tin bath during the float glass process. The coating is basically burned with the glass surface at a temperature around 600℃. The coating is durable and have long shelf-life. The emissivity of this coated glass is 0.15-0.25 and can provide energy efficient functions for windows, doors, curtain walls, etc.
Performance data Sheet:
| Item | Glass Make-up | Visible Light (%) | Solar Energy (%) | Solar Heat Gain Coefficient |
Shading Coefficient |
U-Value (W/M2·K) | |||||
| Trans- mittance |
Reflectance | Trans- mittance |
Reflec- tance |
Absor- ption |
|||||||
| Outside | Inside | Winter Night Time | Summer Day Time |
||||||||
| VLT | LR | LR | ET | ER | EA | SHGC | SC | ||||
| 1 | 6mm DET174II(2#)HS+12A+6mm FGB80(#4) | 62 | 11 | 13 | 30 | 26 | 39 | 0.36 | 0.42 | 1.32 | 1.21 |
| 2 | 6mm DET160II(2#)HS+12A+6mm FGB80(#4) | 50 | 21 | 22 | 25 | 28 | 44 | 0.30 | 0.35 | 1.32 | 1.21 |
| 3 | 6mm DET157II(2#)HS+12A+6mm FGB80(#4) | 47 | 14 | 14 | 22 | 36 | 39 | 0.26 | 0.30 | 1.30 | 1.19 |
| 4 | 6mm DET144(2#)HS+12A+6mm FGB80(#4) | 36 | 16 | 13 | 16 | 35 | 47 | 0.21 | 0.24 | 1.32 | 1.21 |
| 5 | 6mm DET136(2#)HS+12A+6mm FGB80(#4) | 28 | 16 | 18 | 12 | 29 | 57 | 0.18 | 0.20 | 1.32 | 1.21 |
| Product Name | Hard Coated Low-E FGB80 |
| Max Size | 3300mm×4880mm (Automatic line) |
| Min size | 300*300mm |
| Glass thinkess | 5mm-6mm |
| Color of the glass | clear |
| Processing types |
Common Tempered, laminated, tempered laminated, Insulated glass, ETC |
| Processing capacity | 400 Ton / Day |
| Application |
1. Window etc. |
Product Feature:
1. Low emissivity down to 0.15;
2. Can be used monolithically;
3. Can be tempered (flat or curved);
4. Can be laminated on #2 & #4 surface;
5. Can be insulated on #2 and/or #4 surface;
6. Can be printed;
