Polyamide Engineering Plastic Extrusion Thermal Break Strip for Aluminum Insulation System Window
Product Description
Our Polyamide Strip is specially designed to enhance the performance of your aluminum doors and windows. By using our high precision polyamide thermal break strip, you can enjoy excellent thermal insulation and sound insulation properties. Say goodbye to drafts and noise, and hello to a cozy and peaceful environment.
The shape CT thermal barrier polyamide strip can prevent the window frame from dust and water, has a better mechanical performance, is the first generation and easiest shape of insulating strips.
For the shape CT, we can provide the following size or customize according to customers' requirements.
Detailed Infomation
Advantages
- When spraying, the temperature is as high as 300 ℃, which fully meets the process operation of first piercing strip and then spraying.
- Dimensional accuracy can be less than 0.05 mm. The high dimensional accuracy is easy to operate roll extrusion processing.
- The strips are excellently processed, which will fasten the furniture hardware.
- It has such properties as fire-resistance, thermostability, corrosion resistance, aging resistance and uvioresistant. Therefore, they are environmentally friendly with a longer life span. Also, they can be recycled for reuse.
Application
It is mainly used in insulation broken bridge aluminium products, helping to reduce heat loss or heat gain through the aluminum, and has better performance in terms of power usage.
Product Parameters
|
Name
|
Specification
|
Brand
|
Material
|
|
Nylon Thermal Break Strips
|
PW-CT04
|
Polywell |
PA66 GF25
|
|
Item
|
Unit
|
GB/T 23615.1-2009
|
PW-Technical specification
|
|
Density
|
g/cm3
|
1.3±0.05
|
1.28-1.35
|
|
Linear expansion coefficient
|
K-1
|
(2.3-3.5)×10-5
|
(2.3-3.5)×10-5
|
|
Vicat softening temperature
|
ºC
|
≥230ºC
|
≥233ºC
|
|
Melting point
|
ºC
|
≥240
|
≥240
|
|
Testing for tensile cracks
|
-
|
No cracks
|
No cracks
|
|
Shore hardness
|
-
|
80±5
|
80-85
|
|
Impact strength(Unnotched)
|
KJ/m2
|
≥35
|
≥38
|
|
Tensile strength(longitudinal)
|
MPa
|
≥80a
|
≥82a
|
|
Elasticity modulus
|
MPa
|
≥4500
|
≥4550
|
|
Elongation at break
|
%
|
≥2.5
|
≥2.6
|
|
Tensile strength(transverse)
|
MPa
|
≥70a
|
≥70a
|
|
High temperature tensile strength(transverse)
|
MPa
|
≥45a
|
≥47a
|
|
Low temperature tensile strength(transverse)
|
MPa
|
≥80a
|
≥81a
|
|
Water resistance tensile strength(transverse)
|
MPa
|
≥35a
|
≥35a
|
|
Aging resistance tensile strength(transverse)
|
MPa
|
≥50a
|
≥50a
|
1. Sample water content less than 0.2% by weight.
2. Norm laboratory condition:(23±2)ºC and (50±10)% relative humidity.
3. The specifications marked with "a" only applies to I-shape strip otherwise, the specifications concluded between supplier and buyer through consultation, shall be written in contract or purchase order.
Our Service & Company
Before sales
1. Introduce products in detail
2. Recommend suitable solutions
3. Provide with reference information
During manufacturing
1. Provide with layout and engineering conditions
2. Inform the processing status
3. Offer related documents
After Sales
1. Provide installation, commissioning and training
2. Offer spare parts
3. Provide with necessary technical support
FAQ
About Sample
Sample is Free, but the express fee is collect or you pay us the cost in advance.
About MOQ
For the polyamide granules, MOQ is 1 ton. For the thermal break strips, MOQ is 10,000 meters.
About Customizing Special shape of polyamide Profiles and its period
You can customize the special shape of polyamide strips. If we didn't meet this shape before, we will make new mold for you, and you should pay for the mold.
About Customizing Package Style and Marks
You can customize the package style and marks.
Why your price is higher/lower than others?
For years specializing in polyamide granules and thermal break strips has bestowed us experienced and skilled technical workers and production workers. We promise the stability of products and the high-quality of raw material. Furthermore, we can provide technical support from raw material to the final appliance. Believe in that you can get better products and service with lower price.
About warranty
We are confident in our products, and pack them well before delivery, so usually you will receive your order in good condition. Any quality issue, we will deal with it immediately.
About Payment or other question
50% T/T before production, 50% T/T balance before shippment.
If you have any question, pls feel free to contact us as below.
Lydia
E-mail: lydia@szpolywell.cn
Tel: +8615601568506 (WhatsApp)
Address: Yangshe Town, Zhangjiagang City, Jiangsu Province, China.
Packing & Delivery
Packaging details: For all specifications/shapes, they could be packaged in linear, the length will be 6 meters, or customized.For the Shape "I", "C", and some simple shapes, they can be packed in rolls. 400-600 meters/roll.
Delivery details: Shipped in 7-15 working days after payment.
