Production PA66 Parallel Twin Screw Plastic Granulator Machine Raw Material Production Machine
Products Details
PA granulator used to produce PA66GF25 granules. Screw elements and kneading blocks are made of high tool steel, with high wear-resistant and high corresion-resistant. Modular principle destgn for screw configuration and barrel setup makes combination and cleaning convenient.
Competitive Advantage
1.Low power consumption is more energy-efficient and environment-friendly.
2.Low noise, work stable and durable.
3.Modular principle design for screw configuration and barrel setup makes combination and cleaning convenient, also easy to adapt to customers' requirements .
4.Screw elements and kneading blocks are made of high tool steel , with high corrosion-resistant and high wear- resistant.
5.Barrels are made of high quality nitrided steel , corrosion proof and antifriction.
6.Vacuum system fulfills devolatilization to ensure the quality of polymer processing.
7.Through the specific combination of screw, the produced granules are more suitable for the extrusion of nylon profiles.
Parallel Twin-screw Granulator Reference Values
| Operating Capability kg/h | ||||||||
| Process | Materials | 20 | 35 | 50 | 65A | 75A | 95 | 132 |
|
Mixing Nature-changing |
PA | 2-10 | 25-60 | 80-180 | 160-250 | 300-400 | 600-1100 | 800-1800 |
Technical Date of Parallel Twin-screw Granulator
| Model | D(mm) | L/D | Nmax(r/min) | P(kw) | Q(kw) |
| PW-D65 | 62.4 | 24-48 | 400-500 | 55-75 | 200-500 |
| PW-D75 | 71 | 24-48 | 400-500 | 90-110 | 300-600 |
| PW-D95 | 93 | 24-48 | 3000 | 132-135 | 500-1000 |
Our Products
1.Parallel twin-screw granulator
2.PA66 plastic granules
3.Thermal barrier strip of polyamide
4.Extruding machine of thermal barrier strip
5.Aluminum cutting machine
6.Tensile testing machine
(We can provide all products,services and technical support on the production line)
Our Company
Our Company is located in the city of Zhangjiagang, Jiangsu Province, China. We have been making research and development for special material of PA66 thermal insulation strip since 2006.We have a deep understanding and rich experience of the relevant industry during this year.
We expanded our business scope since the year of 2010. We not only produce PA66 granules and PA66 thermal barrier strips, but also sell parallel twin-screw granulator, extruding machine, mould and production technology.
we are developing overseas market. We are going to promote our products all around the world, to seek win-win cooperation, mutual benefits and mutual development with our customers.
Our Service
| Befor sales | 1.Intriduce products in details |
| 2.Recommend suitable solutions | |
| 3.Provide with reference information | |
| During manufacturing | 1.Provide with layout and engineering conditions |
| 2.Inform the processing status | |
| 3.Offer related documents | |
| After sales | 1.Provide installation, commissioning and training |
| 2.Offer spare parts | |
| 3.Provide with necessary technical support |
