En 10223 8*10 2x1x0.5m Woven Gabion Baskets Flood Control Galfan Coated
EN10223 8*10 2x1x1m Flood Control Galfan Coated Woven Gabion Baskets
Floods, landslides, tsunamis, and coastal erosion have all become more common and more intense in recent years. There were an average of 173 lion people per year affected by natural disasters from 2005 to 2022 In the last 10 years, natural disasters have caused an average of $180 Billion in damages each year. Asia and Africa is the most affected continent. In 2015 six out of the ten deadliest disasters occurred on the continent.
Except for metal gabion baskets and gabion boxes, plays an important role in our products for Channel, river, and streamworks.
Nova metal gabion baskets and es are built according to the requirements of ASTM A975 or EN10223.
|
Gabion type* |
Dimensions (m) |
Mesh size (mm) |
||
|
Length |
Width |
Height |
||
|
L |
W |
H |
||
|
2x0.5x0.5 |
2 |
0.5 |
0.5 |
80 x 100 (+/-10%) |
|
2x1x0.5 |
2 |
1 |
0.5 |
80 x 100(+/-10%) |
|
4x1x0.5 |
4 |
1 |
0.5 |
80 x 100(+/-10%) |
|
1x1x1 |
1 |
1 |
1 |
80 x 100(+/-10%) |
|
2x1x1 |
2 |
1 |
1 |
80 x 100(+/-10%) |
|
4x1x1 |
4 |
1 |
1 |
80 x 100(+/-10%) |
|
2x1.5x1 |
2 |
1.5 |
1 |
80 x 100(+/-10%) |
|
6x2x0.5 |
6 |
2 |
0.5 |
80 x 100(+/-10%) |
|
*Other sizes available on request. |
||||
|
Types of Surface Coating : |
||||
|
- heavily galvanized, |
||||
|
- heavily galvanized with polymer coated, |
||||
|
- Galfan coated, |
||||
|
- Galfan coated with polymer coating. |
||||
|
Body wire: |
||||
|
- diameter 2.7 mm + 1mm when polymer coated. |
||||
|
Selvedge wire: |
||||
|
- diameter 3.4 mm + 1mm when polymer coated. |
||||
|
Lacing wire: |
||||
|
- diameter 2.2 mm + 1mm when polymer coated. |
||||
*Other sizes and specifications of gabion box and wire are available on request.
