Brass Mesh 200 Mesh Copper Wire Mesh/ Pure Copper Knitted Gas Liquid Filter Wire Mesh For Alcohol Distillation Equipment
Brass mesh 200 mesh copper wire mesh/ Pure Copper Knitted Gas Liquid Filter Wire Mesh For Alcohol Distillation Equipment
Material: Pure Cooper-99.8%
Mesh Size: 6mesh-200mesh
Wire diameter:0.025mm-5mm
Width: 0.6m-1.2m
Weave: Plain,Twill
| Material |
Brass wire--purity--Cu: 65% , Zn:35% Red copper wire--purity--Cu:99.8% Phoshpor bronze wire--purity--Cu:85%-90% , Sn:5%-15% |
| Features |
Its texture is soft Good at translucent and permeability Suitable for use as a shielding mesh Shielding mesh is not only able to prevent the electromagnetic signals through the display window,but also effectively shielding electromagnetic waves to ensure the electromagnetic instrument to work properly. |
| Woven | Plain weave, twill weave, "human" character of weaving and bamboo weaving |
| Application | For the screen of particles, powder, porcelain clay and glass, porcelain, printing, filter liquid gas |
| Item | Red copper wire mesh | Brass wire mesh |
Phosphor bronze wire mesh |
Tinned copper wire mesh |
| Materail | 99% pure copper wire | H65 wire (65%Cu-35%Zn ) | Tin bronze wire | Tinned copper wire |
| Mesh count | 2-250 mesh | 2-250 mesh | 2-350 mesh | 2-100 mesh |
| Weave type | Plain/ twill/ dutch weave | |||
|
Common size
|
width 0.5-1.5m ;length 30m/roll Aslo can be as per your demand |
|||
| Common feature |
Nonmagnetic , good ductility , Wear resistance , Fast heat transfer, Good electrical conductivity |
|||
| Special features |
Sound insulation; Electron filtration ; |
Apply to Newspaper/typing/chinaware printing usual ; Smoking screen; |
Apply to Chinaware printing, screening all kinds of particles,powders ,and porcelain clay ... |
High temperature resistance , anti-aging ,and long service life |
| Common Applications |
EMI/rfi shielding; Faraday cage ; |
Engine filter to car , Noise reduction , damping(suspension ) |
||
| Sample | Free | |||
| Customized | Acceptable | |||
Phosphorus copper wire mesh, Phosphorus copper mesh etc
Material: Cu-85%-90%,the other 5%-15%
Mesh Size: 6mesh-350mesh
Wire diameter:0.025mm-5mm
Width: 0.6m-1.5m
Weave: Plain,Twill
Production Process:
1. Raw material check
2. Material preparation
3. Finish dia.warping beam
4. Mesh wearing
5. Surface check
Quality Control:
1. Mesh count inspect
Copper Wire Mesh Screen Fabric Features:
♥ Beautiful appearance for decoration.
♥ Good ductility.
♥ Good thermal conductivity and non-magnetic.
♥ Lightweight and high density.
♥ Recyclable.
♥ Excellent EMI/RFI/EMC shielding performance.
♥ Beautiful and attractive surface.
♥ Non-magnetic.
♥ Excellent electrical conductivity.
1.Can I get a sample before placing orders?
Of course! We are glad to provide samples to you or your customer. You will find that our products are genuine at fair prices.
2.Can you make customized mesh for special application?
The answer is YES. Our skilled employees are so experienced. They are very capable to manufacture bespoke wire meshes according to your special requirements.
3. How long is your delivered time?
Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
