180 - 240V / AC 12w Dimmable Led Driver Constant Voltage Short Circuit Proof
High Quality 12w constant current led driver Support Dali Agreement
Product Features:
Selectable constant current and constant voltage output.(Custom on request)
Full-ioslated,delivering up to 12W of power
Short circuit,over current and over voltage protection
Fireproof environmental protection PC plastic cover
5 years quality warranty
Specification:
| Input Voltage range:90-130&180-240V/AC |
| Input Frequency range:50-60Hz |
| Input Power factor:>0.95 |
| Input Full load efficiency:≥85% |
| Input AC current:0.12A/0.06A |
| Input Rated current:350mA |
| Output Current accuracy:±5% |
| Output voltage range:24-34V |
| Output Rated pwer:12W |
| Net weight:80g |
| Size:94*36*18mm |
Conformance with regulations
EN 55015
EN 61000-3-2-CLASSIC
EN 61000-3-3
EN 61000-4-2,3,4,5,6,8,11
EN 60598
Shell structure:
FAQ:
- What is intelligent lighting control system?
A lighting control system is an intelligent network based lighting control solution that incorporates communication between various system inputs and outputs related to lighting control with the use of one or more central computing devices. Lighting control systems are widely used on both indoor and outdoor lighting of commercial, industrial, and residential spaces.
- What is the advantage compare with the traditional lighting control?
- Improve energy efficiency
- Reduce maintenance cost
- Easy operation and more convenient
- What Okystar can supply for you?
Okystar can offer a whole solution of lighting control system for you, economic and customization, with industrial-grade design, product architecture in line with international electrical standards, using high-quality components, products are stable and reliable. And we have technical team to support skype is okystar22 to you.
