Architecture Agriculture 1.0Mpa 15kW Hose Concrete Pump

Price Negotiable

Price: Negotiation

MOQ: 1 Set

Delivery Time: 10~30 Work Days

Brand: KEMING

Product Description

Large Output Hose Type Concrete Pump For Pumping Concrete From China

1. Compact size: hopper with agitator, hose pump, power combined in a base frame.
2. Soft start: electric motor smoothly start and protect the motor
3. Low wear: the squeeze hose is the only wear part of the pump and can be replaced very quickly
4. Delivers even the most difficult materials

1. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.
2. Architecture: mortar,plaster,cement paste,soil slurry,silt slurry,lime slurry,foamed concrete, architectural coating, refractory,accelerator,ooze,waste water,sewage and so on.
3. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.
4. Oil industry: drilling fluid,crude oil.
5. Ceramic industry: ceramic germ plasma, slip glaze, glaze materials.
6. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...
7. Paper industry: paper pulp, liquid sulfur.
8. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.
9.
10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.

Model	KH76B Squeeze Hose Pump
Output	18000~28000 L/h
Rated pressure	1.0 MPa
Rev.	40~55 r/min
Hose length	1900 mm
Max. particle dia.	6 mm
Max. suction dist.	5 m
Motor power	11.0/ 15.0 KW
Reducer type	Cycloidal reducer
Note: 1. Driven power could be electric motor or diesel engine. 2. Various squeeze hoses are available for pumping different materials. 3. Customized pump is available.
