150mm Outlet 25m3/H Dry Mix Shotcrete Machine Hydraulic Type
Best-selling KEMING KBT series mixing concrete pump machine with double function
KEMING mixing concrete pump machine Introduction:
1. Mxing Concrete Pump machine combines concrete mixer and concrete pump as one new concrete pumping machine with concrete mixer.
2. Concrete mixer pump machine has double cylinder hydraulic pump system with reliable performance.
3. Concrete Mixer Pump machine spare parts are from high quality products of famous brand.
KEMING mixing concrete pump machine Features:
1. compact structure, flexible movement, easy operation and simple maintenance.
2. remote control with high automatic degree and easy operation, saving labor cost.
3. independent mixing system with even mixing performance and high working efficiency.
4. double cylinder hydraulic pump system with high pumping speed and high working efficiency.
5. advanced S-tube distribution valve, well sealing techinc, good sealing performance.
KEMING mixing concrete pump machine Parameters:
| Items | Unit | Parameters | |||||
| KBT2506/JZM450 | KBT2506/JZM350 | KBT2006/JZM300 | KBT20/JZC350 | KBT0804/JZC200 | |||
| Capacity | m3/h | 25(18) | 25(18) | 20(13) | 20(15) | 8(6) | |
| Max. aggregate size | mm | 40 | 40 | 40 | 40 | 30 | |
| Delivery pipe | mm | DN125 | DN125 | DN125 | DN125 | DN125 | |
| Max. dist | horizontally | m | 200 | 200 | 150 | 150 | 100 |
| vertically | m | 80(60) | 80(60) | 60(40) | 60(40) | 30 | |
| Mixer type | JZM450 | JZM350 | JZM300 | JZC350 | JZC200 | ||
| Charge hopper | L | 720 | 560 | 500 | 560 | 300 | |
| Discharge hopper | L | 450 | 350 | 300 | 350 | 200 | |
| Diameter of drum | mm | 1550 | 1440 | 1260 | 1440 | 1000 | |
| Output pressure | Mpa | 6-8 | 6-8 | 5-8 | 5-8 | 3-5 | |
