TESA 60262 Gray Black Double-sided Adhesive Conductive Non-woven Tape
TESA 60262 gray black double-sided adhesive conductive non-woven tape
Product description :
- TESA 60232 is a matte black single side conductive self-adhesive tape. It is composed of conductive fiber substrate and conductive acrylic adhesive system.
Product features :
- Thickness: 50 μm
- Excellent shear resistance and die-cutting
- Even at high temperatures and humidity, the tape maintains good electrical conductivity in the XYZ direction
- High bonding ability even in harsh environments
Product Application :
- Fixing of electronic components: reflective panels and film materials in the backlight of microLcds such as mobile phones
- Electromagnetic wave management: electromagnetic wave absorption plates and thin film materials in fixed microelectronic machines
- EMC applications: ground and electrostatic discharge point applications
PRODUCT PARAMETERS
|
|
TESA | Model | 60262 |
|
|
Non-woven | Color | Gray black |
|
|
PE coated paper | Adhesive | Acrylic acid |
|
Total thickness (μm) |
|
Specification |
1040mm × 50m (Customizable) |
PROPERTIES / PERFORMANCE VALUES
|
Contact resistance z direction (initial)
(Ohm / square inch) |
0.02 Ohm / square inch
|
Short-term high temperature resistance (℃) |
200 ℃ |
| 40°C static shear resistance |
Very good
|
Long-term high temperature resistance (℃) |
100 ℃
|
|
Surface resistance x-y direction (mOhm / square) |
0.2 mOhm / square
|
Release force |
Easy
|
PEEL STRENGTH PARAMETER VALUE
| Material |
Initial Adhesion
|
Adhesion after 14 days ( N/cm ) |
| Steel |
5.4
|
8.3 |
