BERGQUIST GP3000S30 Battery Pack Gap Filled Thermally Conductive Silicon Pad 3.0W/M-K
BERGQUIST GP3000S30 Battery pack Gap filled Thermally Conductive silicon Pad 3.0W/m-k
Product description :
- BERGQUIST GP3000S30 Soft thermal conductive material with substrate gap filling. Also known as GAP PAD 3000S30. The new model is GAP PAD TGP 3000.
Product Features :
- Under very low pressure, low S-Series thermal resistance, high adhesion, S-Series softness
- Designed glass fiber reinforcement for low stress applications to improve workability and tear resistance
Product Applications :
- Processor Server S-RAMS
- Mass storage drive
- Wired/wireless communication hardware
- Laptop
- Power converter
|
Model
|
GP3000S30 |
|
Material
|
Fiberglass |
|
Glue
|
Double sided self-adhesive |
|
Thermal Conductivity (W/m-k) |
3.0
|
|
Thickness (mm) |
0.25mm 0.51mm 1.02mm 1.52mm 2.03mm 2.54mm 3.18mm
|
|
Dielectic Breakdown Voltage (Vac) |
＞3000
|
|
Continous Use Temp (℃) |
- 60 ~ 200
|
