Lightproof Aluminum Foil Inner Bag Of Container Bag For New Energy Chemical Food Industrial Material Packaging
Lightproof Aluminum Foil Inner Bag Of Container Bag For New Energy Chemical Food Industrial Material Packaging
Based on the explosive growth of raw material products such as lithium batteries, degradable plastic particles, nylon and so on, we quickly laid out solid soft packaging business in inner bag of container bags and introduced the first full-servo high-speed automatic production line in China to improve production efficiency. At the same time, we continue to improve the characteristics of different film materials, strictly control the magnetic ad non-magnetic physical standards of the workshop, to make the inner bag is more anti-oxidation, moisture resistance, corrosion resistance, pollution-free, and give the container bag a wider range of safer material performance and application.
| Product Type | Inner Bag of Container Bag/Ton Bag |
| Material Structure | PET/AL/PA/PE;PE/AL/PA/PE; PET/VMPET/PE |
| Core Features | Anti-oxidation, moisture/corrosion resistance, anti-kneading, high barrier, puncture resistance, lightproof, soft texture, stable oxygen permeability, wear resistance, high tensile strength |
| Mechanical Properties | Tensile force ≥30-100 N/15mm, puncture resistance ≥3-12 N, excellent anti-kneading performance, elongation at break ≥200% |
| Application | Lithium battery cathode/anode materials, degradable plastic particles, food powder/solids, chemical intermediates/powders, daily chemical intermediates, nylon particles |
| Production | Full high-speed automatic production line; non-magnetic physical workshop; pollution-free production process |
| Product name | Structural composition | Product feature |
|
Aluminum foil inner bag
The surface material is PET |
 |
It has the characteristics of anti-rubbing, not easy to break, soft, stable overall oxygen permeability and so on |
|
Aluminum foil inner bag
The surface material is PET |
 |
The surface material is 100% PE, it has the advantage of aluminum foil inner bag but more soft. |
|
VMPET inner bag
The surface material is PET
|
 |
It has high tensile strength, high barrier, puncture resistance, kneading resistance and many other mechanical properties. |
| Inspection item | Standard requirement | |||||
| PET/AL/NY/CPE | CPE/AL/NY/CPE | PET/NY/CPE | PET/VMPET/CPE | CPE/CPE | VMPE/CPE | |
| Pulling strength(N/15mm) | ≥100 | ≥80 | ≥80 | ≥80 | ≥30 | ≥30 |
| Breaking Elongation(%) | ≥80 | ≥80 | ≥80 | ≥80 | ≥300 | ≥300 |
| Resistant to pendulum impact (J) | ≥2.0 | ≥2.0 | ≥2.0 | ≥1.0 | ≥1.0 | |
| Oxygen transmittance cm3/(㎡.24h.0.1mpa) | ≤0.5 | ≤100 | ≤2 | - | ≤100 | |
| Water vapor transmittance g/(㎡.24h) | ≤0.5 | ≤10 | ≤2 | ≤15 | ≤2 | |
| Combined strength(N/15mm) | PET/AL ≥2.5 | PE/AL ≥2.5 | PET/NY ≥2.5 | PET/NY ≥2.5 | CPE/CPE ≥2.5 | VMPE/CPE ≥2.0 |
| AL/NY ≥3.5 | AL/NY ≥3.5 | NY/CPE ≥5 | NY/CPE ≥5 | - | - | |
| NY/CPE ≥5 | NY/CPE ≥5 | - | - | - | - | |
| Heat sealing strength(N/15mm) | ≥100 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 |
| Puncture strength(N national standard) | ≥12 | ≥8 | ≥10 | ≥10 | ≥3 | ≥3 |
1. Enhanced Shape Adaptability
This aluminum foil inner bag of container bag can be made into cube, irregular block and other shapes according to the storage container and material characteristics. It fits closely with the inner space of the container bag without leaving gaps, maximizing the utilization of storage space.
2. Reinforced Sealing Performance
The sealing port of the inner bag adopts a heat-sealing + tying dual fixation design, which can effectively prevent air leakage and material spillage during transportation. It also avoids the volatilization of chemical intermediates and the moisture absorption of lithium battery materials.
3. Superior Temperature Insulation
The aluminum foil and VMPET composite layer of the inner bag has good thermal insulation performance, which can reduce the impact of external temperature changes on the packaged materials. It is especially suitable for the storage and transportation of temperature-sensitive lithium battery raw materials and food powder.
4. Easy Operation & Handling
The inner bag is light in weight and flexible in texture, which is convenient for manual or mechanical loading and unloading into the container bag. Its reinforced lifting part design also makes the hoisting and transferring process more stable and labor-saving.
5. Long-term Material Preservation
Thanks to the multi-layer composite structure of PET/AL/PA/PE, the inner bag can maintain the sealed environment inside for a long time, effectively preventing the oxidation of lithium battery cathode/anode materials and the mildew of food solids for up to 12 months under normal storage conditions.
6. Compatibility with Multiple Filling Equipment
The inner bag is designed with a matching filling port size, which is compatible with common industrial filling equipment such as powder fillers and particle dispensers. It can realize fast and accurate material filling without additional adapter parts.
The application of ton bag:
All suitable for the ton bag packaging industry, like new energy lithium battery industry, chemical raw materials, pharmaceutical raw materials, plastic raw materials, food additives, feed additives, metallurgical powder, ore powder, sand and gravel, refractory materials and so on, the container bags mainly pack block, granular or powdered items, and the physical density and looseness of the contents also have a significantly different impact on the overall result.
