High Barrier Lightproof Aluminum Foil Inner Bag Of Container Bag For Lithium Battery Food Chemical Packaging
High Barrier Lightproof Aluminum Foil Inner Bag Of Container Bag For Lithium Battery Food Chemical Packaging
Based on the explosive growth of raw material products such as lithium batteries, degradable plastic particles, nylon and so on, we quickly laid out solid soft packaging business in inner bag of container bags and introduced the first full-servo high-speed automatic production line in China to improve production efficiency. At the same time, we continue to improve the characteristics of different film materials, strictly control the magnetic ad non-magnetic physical standards of the workshop, to make the inner bag is more anti-oxidation, moisture resistance, corrosion resistance, pollution-free, and give the container bag a wider range of safer material performance and application.
| Product Type | Inner Bag of Container Bag/Ton Bag |
| Material Structure | PET/AL/PA/PE;PE/AL/PA/PE; PET/VMPET/PE |
| Core Features | Anti-oxidation, moisture/corrosion resistance, anti-kneading, high barrier, lightproof, puncture resistance, wear resistance, soft texture, stable oxygen permeability, high tensile strength |
| Mechanical Properties | Tensile force ≥30-100 N/15mm, puncture resistance ≥3-12 N, elongation at break ≥200%, excellent anti-kneading & tear resistance |
| Application | Lithium battery cathode/anode materials, food powder/solids, chemical intermediates/powders, daily chemicals, degradable plastic particles, nylon particles, pharmaceutical raw materials |
| Production | Full high-speed automatic production line, non-magnetic physical workshop, pollution-free manufacturing, food-grade production standard compliance |
| Product name | Structural composition | Product feature |
|
Aluminum foil inner bag
The surface material is PET |
 |
It has the characteristics of anti-rubbing, not easy to break, soft, stable overall oxygen permeability and so on |
|
Aluminum foil inner bag
The surface material is PET |
 |
The surface material is 100% PE, it has the advantage of aluminum foil inner bag but more soft. |
|
VMPET inner bag
The surface material is PET
|
 |
It has high tensile strength, high barrier, puncture resistance, kneading resistance and many other mechanical properties. |
| Inspection item | Standard requirement | |||||
| PET/AL/NY/CPE | CPE/AL/NY/CPE | PET/NY/CPE | PET/VMPET/CPE | CPE/CPE | VMPE/CPE | |
| Pulling strength(N/15mm) | ≥100 | ≥80 | ≥80 | ≥80 | ≥30 | ≥30 |
| Breaking Elongation(%) | ≥80 | ≥80 | ≥80 | ≥80 | ≥300 | ≥300 |
| Resistant to pendulum impact (J) | ≥2.0 | ≥2.0 | ≥2.0 | ≥1.0 | ≥1.0 | |
| Oxygen transmittance cm3/(㎡.24h.0.1mpa) | ≤0.5 | ≤100 | ≤2 | - | ≤100 | |
| Water vapor transmittance g/(㎡.24h) | ≤0.5 | ≤10 | ≤2 | ≤15 | ≤2 | |
| Combined strength(N/15mm) | PET/AL ≥2.5 | PE/AL ≥2.5 | PET/NY ≥2.5 | PET/NY ≥2.5 | CPE/CPE ≥2.5 | VMPE/CPE ≥2.0 |
| AL/NY ≥3.5 | AL/NY ≥3.5 | NY/CPE ≥5 | NY/CPE ≥5 | - | - | |
| NY/CPE ≥5 | NY/CPE ≥5 | - | - | - | - | |
| Heat sealing strength(N/15mm) | ≥100 | ≥80 | ≥80 | ≥80 | ≥80 | ≥80 |
| Puncture strength(N national standard) | ≥12 | ≥8 | ≥10 | ≥10 | ≥3 | ≥3 |
1. Ultra-High Barrier Performance
This aluminum foil inner bag of container bag features multi-layer composite structures like PET/AL/PA/PE, which achieves excellent barrier effects against oxygen, moisture and light. It can effectively isolate external air, water vapor and light irradiation, preventing the deterioration of lithium battery materials, food powder and chemical raw materials during storage and transportation.
2. Superior Mechanical Strength
With tensile force ≥30-100 N/15mm, puncture resistance ≥3-12 N and elongation at break ≥200%, the inner bag has strong anti-kneading and tear-resistant properties. It can withstand the friction and collision in industrial handling, loading and unloading, ensuring no damage to the packaged materials.
3. Wide Industrial Applicability
The inner bag is suitable for packaging various materials including lithium battery cathode/anode materials, degradable plastic particles, food solids/powders, chemical intermediates, daily chemical raw materials and nylon particles, meeting the packaging needs of new energy, food, chemical and pharmaceutical industries.
4. Customizable Design
We support full customization of the inner bag, including size adjustment according to FIBC/ton bag specifications, thickness modification based on packaging requirements, and shape customization such as cube and irregular block. Printing service for logos and product information is also available.
5. High Material Safety
Adopting composite materials, the inner bag is non-toxic, odorless and pollution-free. It complies with food safety and industrial material packaging standards, making it safe for contact with food powder and pharmaceutical raw materials.
6. Eco-Friendly Production & Material
Produced in a non-magnetic physical workshop with a full high-speed automatic production line, the manufacturing process is pollution-free. We also provide recyclable mono-material options, reducing environmental impact and meeting the green packaging requirements of modern industries.
The application of ton bag:
All suitable for the ton bag packaging industry, like new energy lithium battery industry, chemical raw materials, pharmaceutical raw materials, plastic raw materials, food additives, feed additives, metallurgical powder, ore powder, sand and gravel, refractory materials and so on, the container bags mainly pack block, granular or powdered items, and the physical density and looseness of the contents also have a significantly different impact on the overall result.
