MF-800 Industry Disc Plastic PET Grinding Milling Machine Factory Price
The main application fields of plastic grinding milling machines are as follows:
![]()
General description
The Waste Plastic Pulverizer Machines are available with a disc diameter from 300 to 800 mm. These plastic pulverizer machines are high speed, precision grinders for the processing of medium-hard, impact-resistant, and friable materials. The material to be pulverized is introduced through the center of a vertically fixed grinding disc which is mounted concentrically with an identical high speed rotating disc. Centrifugal force carries the material through the grinding area and the resulting powder is collected with a blower and cyclone system. Depending on the application the machines can be equipped with one-piece grinding discs or grinding segments.
Performance characteristics of Plastic PET grinding milling machine:
A1: The new disc design is used ,high-yield,strong resistance and the life of grinding disc is double the ordinary.
A2: The use of newly designed professional bearings ,and reached a high rotation rate ,at the same time using only one drive motor ,to ensure the efficient grinding crash,which greatly saves the time and operation of machinery and control engineering .
A3: Installation and maintenance easy ,open the door to cover clean-up
A4: Milling process of the whole seal,without dust leakage
A5: Full automated ,automatic feeding ,the materials and sorting
A6: Grinding gap adjustment is simple ,just use the plug-foot bolts and adjustments can be fine-tuning
the host used the water and wind double cooling system ,rational design of smaller cross-section of the grinding chamber ,grinding is almost flat vertical surface.material entered the grinding chambers soon as caught, ground,and then rapidly removed,which eliminates the grinding chamber of the surge in materials,heating materials to avoid decomposition,resulting in improved production.
![]()
Technical datas of Industry plastic milling machine:
|
Item Model
|
MF-400
|
MF-500
|
MF-600
|
MF-800
|
|
Main Motor(KW/hp)
|
22/30
|
37/50
|
45/60
|
45/100
|
|
Total Power(KW/hp)
|
26/35
|
44/59
|
54/72
|
88/118
|
|
Blade Material
|
SKD-11
|
SKD-11
|
SKD-11
|
SKD-11
|
|
Capacity
|
50-300kg/hr
|
80-500kg/hr
|
120-800kg/hr
|
200-1200kg/hr
|
|
Vibration Sieve
|
ZDS-800
|
ZDS-1000
|
ZDS-1000
|
ZDS-1200
|
|
Dimensions(mm)
|
2600x2200x3600
|
3000x2800x3900
|
3200x3000x4200
|
3500x3200x4500
|
|
Weight(kg)
|
1680
|
2280
|
2680
|
3580
|
General Specification of Plastic milling machine:
| Model | Motor Power | Total Power | Vibration Sieve | Output | Weight | Dimension |
| MF-400 | 22kW | 26kW | 800mm | 50~300kg/hr | 1680KGS | 2.6*2.2*3.6m |
| MF-500 | 37kW | 44kW | 1000mm | 80~500kg/hr | 2280KGS | 3.0*2.8*3.9m |
| MF-600 | 45kW | 54kW | 1000mm | 120~800kg/hr | 2680KGS | 3.2*3.0*4.2m |
| MF-800 | 75kW | 88kW | 1200mm | 200~1200kg/hr | 3580KGS | 3.5*3.2*4.5m |
Zhangjiagang Beisu Machinery Co,Ltd is a certified manufacturer, exporter and supplier of
plastic PVC/PE/PP/PET/EVA/ABS processing machinery. Due to our constant commitment to
extrusion technology, we have emerged as a leading manufacturer of Plastic Extrusion
Machinery for PVC pipes Extrusion Line, HDPE pipes Extrusion Line, PVC compounding
Extruder, PPR Pipes Extrusion Line, PVC profiles Extrusion Line.
Especially High speed Plastic mixer, PVC compounding mixer, SPC mixer.WPC mixer,Plastic Granulating and Pelletizing Line,Plastic pvc pelletizing machine,Soft PVC shoes granulator, PVC compounding pelletizer and Plastic PVC pulverizer, PVC miller,SPC milling machine, WPC pulverizer, SPC pulverizer, PE pulverizer,LDPE pulverizer,PET pulverizer,ABS pulverizer,HDPE pulverizer,Plastic pulverizer, Plastic milling machine, Plastic miller machine,Plastic Crusher,PVC crusher,PE crusher,PP shredder, Plastic PVC Shredder etc for a wide range of extrusion processes.
1. Before shipment testing at factory, vedio record.
2. Vedio instruction for operation.
3. User manual and installation instruction, layout and drawings.
4. Lable&marks for disassemble parts, wiring&cables.
1.Reliable
-
Most popular design with years' verification.
-
Mature supply chain for raw materials with strict quality assurance.
-
International famous brands of key parts i.e. ABB invertor, Siemens electronics, Siemens motor, Mettler Toledo scale etc.
2. Economy
-
BEISU Stable technology commercialized in China.
-
High efficiency mixing performance.
-
Cost effective solutions.
Real time communication SNS group chat(WeChat preferred, Skype/WhatsApp) which includes buyer side and BEISU service team is created for technical assistance in the quickest manner. Scheduled video calls are also available. Just as the company vision 'Customer Oriented' says,BEISU always stands at customer's point to offer the optimum solution and help customer to maximize profit. BEISU has its own customer management system and spare parts management system which ensure quickest responds and enough regular easy-wearing parts whenever customer requests.
