PVC Wood Plastic Composite Production Line Automatically High Speed 380 V
Product Description
PVC Profile Production Line
1.suitable to produce PVC series profile, such as PVC cable trunking, PVC ceiling, PVC decking, flooring, PVC windowsill and door frame and board widely.
2. Conical twin-screw extruder is perfect, with PVC powder or granular material.
3. Mould designed by different kinds of profile customer required.
4. supply formula guide and staple raw material purchase.
The Working Process
PVC powder +other addictive →mixing material by mixer →powder feeder →conical twin-screw extruder →Die &mould →stainless steel vacuum calibration platform →hauls-off machine →cutter →stacker
Machine List
| No. | Machine | Qty. |
| 1 | Spring feeder | 1 set |
| 2 | SJZ51/105 conical twin screw extruder | 1 set |
| 3 | Mould | 2 sets |
| 4 | Vacuum calibration table | 1 set |
| 5 | Haul off unit | 1 set |
| 6 | cutter | 1 set |
| 7 | Stacker | 1 set |
Project evaluation
Raw Material
| Raw material & formulation | PVC Powder & CaCo3, and other additives |
| Final product & Output capacity | PVC Profile & 100～120kg/hr (depending on finished product) |
| Application | Decking, Flooring, Ceiling, Windows and other profiles |
Work Condition (provide by customer)
| Warehouse/Workshop |
Dimension (M*M*M): 25m (Length)×2m(width) × 2.4m (Height) Crane: Machine positioning |
| Temperature & Humidity | ≤40℃ |
| Power supply & Installation | 3-phase, 380 V, 50 Hz |
| Wire/cables | Wires/cables from power supply to control cabinet of this extrusion line; |
| Cooling Water hose/pipe | Water supply to machines and pools |
| Lubrication oil | Exxon mobile |
| Compressor | Supply compressed air |
| Manpower | 1 person |
About Jiangsu ACEMIEN Machinery:
Jiangsu ACEMIEN Machinery Co., Ltd is specialized on plastic extrusion and recycling machinery manufacturing.
We have been producing and selling for over 6 years. Our equipment is exported to Asia, Africa, etc,
We have top-ranking Research and Development technology system and rich experienced technician team.
Our vision is to offer you the best and the most appropriate plastic extrusion and recycling solution, to offer you the most reliable technically and commercial service support.
Turnkey project service:
1. we will provide all the machines for the complete production according to customer's requirements.
2. we will provide complete service for factory layout and other information to help customer to build the factory.
3. we can also provide the raw material to the customer if you need.
4. we will provide good service for machine installation and training, until the customers can run the machines and make stably production.
5. Except one year quality guarantee, we will provide after-sell service for all the life.
6. For long-term cooperation, we always provide good quality, good price and good service to customer. we are the professional and trustable supplier for turnkey projects. Let us do win-win business together.
