Accurate Flow Measurement Robust Leak-Proof Seal Orifice Flange ASMEB16.5 Class150

1. Product Description
An Orifice Flange is a specialized type of flange assembly used to measure the flow rate of liquids or gases in a pipeline. It consists of a pair of flanges, orifice plates, jacking screws, and tapping holes. The key component, the orifice plate, is a thin plate with a precise, concentric bore that is securely mounted between the two flanges.

2. Product Purpose
The primary purpose of an Orifice Flange is to facilitate the accurate measurement of fluid flow. It creates a restricted flow path, causing a predictable pressure drop across the orifice plate. By measuring this pressure difference through the flange taps, the flow rate can be calculated using established engineering standards.

3. Product Advantages
Standardized Design:Ensures consistent and reliable flow measurement according to international standards (ASME, ANSI, ISO).
Robust & Leak-Proof:Provides a secure, sealed assembly for safe operation under high pressure and temperature.
Ease of Installation & Maintenance:** The integrated design allows for straightforward installation and the jacking screws enable easy plate inspection or replacement without disassembling the entire pipeline.

Orifice Flange

FAQ

Q1: What is product can you buy from Jiantuo? A1: Various sizes and models of flanges and pipe fittings, and we accept customized.
