Brass Thread ASTM B564 Nickel Alloy Tube Fittings
Customized brass thread connecting compression fitting copper tube fittings
| Model NO. | TUJXV7722 |
| Finish | Polishing |
| Pressure Rating | 6000LBS |
| Certification | TUV,SGS |
| Trademark | TU-POLY |
| Specification | 300*300*400 |
| HS Code | 3322960948 |
| Wall Thickness | 2mm |
| Product Type: | Welding brass fittings |
| Material: | Brass ( DZR/CW602, HPB58-3 and so on) |
| Color: | Natural or nickle plated |
| Technical: | Hot Forging |
| Feature: | Fittings for heating water supply |
| Thread: | Thread made in accordance with ISO 228-1 or ISO7-1 |
| Size: | 16x1/2",16x3/4",20x1/2",20x3/4",25x3/4",25x1",32x1" |
| Type | Copper Nickel alloy Elbow, Inconel Alloy Steel Elbows, ASTM AB564 , NO6600/ Alloy 600, NO6625/ Alloy 625, Alloy 690, Alloy 718 |
| Package | Wooden cases, pallets, nylon bags or according to the customers' requirements |
| MOQ | 1pcs |
| Delivery time | 10-100 days depending on quantity |
| Payment terms | T/T or Western Union or LC |
| Shipment | FCA Tianjin/Shanghai, CFR, CIF, etc |
| Application | Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc |
| Remarks | Other materials and drawings are available. |
【 characteristics 】
· Fastening joints without directional metal sleeves.
· External non-damaging casing.
· Small pressure loss.
· Soft copper tubes can be used.
[usage]
· Used for piping in the same direction from the internal thread,Suitable for the pipe material: nylon tube, nylon tube, soft soft copper tube (C1220T - 0) 04,06.08. 010.012 ; The highest working pressure 1.0 M Р air pressure, test pressure 10mpa using fluid thread section in JIS B 0203; Work taper thread nut of JIS B 0211 grade 2 (metric fine thread)) of thread sealant or no note) bend, double pipe tee joint, assisted with T joint sealant is according to the production order.For cases with sealant, "S" at the end of model.
FAQ
Q: Are you trading company or manufacturer ?
A: We are a manufacturer & trading combo.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the samples for free but do not pay the cost of freight.
Q: How to proceed an order for fittings ?
A. let us know your requirements or application.
B. we quote according to your requirements or our suggestions.
C. Customer confirms the samples and places deposit for formal order.
D. we arrange the production.
Q: Do you offer guarantee for the products ?
A: Yes, we offer 3 years warranty to our products.
