Screw Sesame Seed Oil Press Machine / Cold Pressed Mustard Oil Machine 2600 Mm
6YL-130 A screw oil press machine cold pressed oil machine for sesame
Working priciple:
The working principle is that the oil is extruded from the material embryo and discharged from the slots and oil troughs of the strip and circle rows by the continuous pushing of the material embryo in the squeezing chamber and the change of the space volume of the squeezing chamber from large to small, and the oil can be directly eaten in a barrel after deep filtration of the oil tank.
Technical parameters of oil presser:
|
Model |
6YL-120 |
6YL-130 A |
6YL-150 |
6YL-160 |
6YL-180 |
|
Weight |
1200 kg |
1650 kg |
1800 kg |
1900 kg |
1980 kg |
|
Vacuum power |
1.1 kw |
1.1 kw |
2.2 kw |
2.2 kw |
2.2 kw |
|
3phase |
15 kw |
18.5 kw |
30kw |
30 kw |
37 kw |
|
Squeezer speed |
100-130 |
100-130 |
100-130 |
100-130 |
100-130 |
|
Capacity(kg/h) |
120-160 |
160-280 |
220-450 |
300-600 |
400-750 |
|
Dimension(mm) |
2000*1600*2700 |
2600*1600*2700 |
2550*1800*2700 |
2650*1900*2700 |
2700*2000*2700 |
Basis Information of Screw Oil Press Machine:
The oil press machine is a new research improvement product. It can use to press Copra, rapeseed, peanuts, soybean, sesame,sunflowerseeds and other plant oil materials. This kind of machine adopts micro-electrical control, filter system, multi-stage press and cold and hot press. The product oils the clean oil after filtering, it can directly to use. The machine is the most ideal equipment for individual processing.
6YL series spiral oil press is mainly composed of 7 major parts of screw axis, press cage, feed mechanism, cake yielding mechanism. transmission system, electric control part and vacuum filter part. All the parts are assembled on the frame and screwed as a whole.
Detailed images
Parts of high quality oil presser:
1. Energy Saving: The electric power can be reduced by 40% under the same output.
2. Labor Saving: 60% labor can be saved under the same output.
3. Widely Usage: The machine is multi-function. It can process more than 20 kinds of oil crops.
4. Pure Oil: Vaccum filter can filter the residue and ensure the oil quality.
5. Small Area Covering: 10 ~ 20 m2 can meet the production needs
Seeds application of screw oil making machine
If you want to process other special raw material, please cantact us to ensure.
Machines Workflow:
