Cold Press Industrial Oil Press Machine peanut Oil Extracting For Oil Mill
cold press soybean oil extracting machine for oil mill factory
Advantage:
1.Safety and durability
1). Motor cover: It can protect the motor service life and safety of people.
2). Internal temperature control parts: It can release the pressure automatically when the working pressure higher than 60Mpa.
3). Large screw: This part can protect the user and machine safety.
4). Pressure release valve: It will release the pressure when over the working pressure.
High oil yield
1). Internal temperature control parts can solve the problem of low oil yield in winter.
2). The oil line is precise, it will filter the residue so can get more oil.
3). Working pressure is 60Mpa is higher than others, it can press raw material cleaner .
4). Solid piston can provide stronger power to press raw material.
Hydraulic oil press machine parameters
| Model | Pressure | Power(3 phases) | Capacity(kg/batch) | Weight(kg) | Dimension(mm) |
| 6YY-185 | 60mpa | 1.1kw | 4 | 590 | 600*880*1150 |
| 6YY-230A | 60mpa | 1.1kw | 8.5 | 924 | 670*950*1460 |
| 6YY-230B | 60mpa | 1.1kw | 9.5 | 950 | 670*950*1560 |
| 6YY-250 | 60mpa | 1.1kw | 11 | 1070 | 710*950*1560 |
| 6YY-270 | 60mpa | 2.2kw | 13.5 | 1230 | 750*1010*1640 |
| 6YY-300 | 60mpa | 2.2kw | 16 | 1600 | 1000*1100*1660 |
| 6YY-335 | 60mpa | 2.2kw | 20 | 1750 | 1100*1240*1730 |
| 6YY-355 | 60mpa | 3.0kw | 23 | 2350 |
1160*1200*1810 |
Diversity of materials and ways of extracting oil
1)There are two ways to press oil: cold press and hot press.
2)Applicable to oil producing crops of various seeds, peanuts, soybeans, olives, etc. Common oil extracting materials are as follows:
Features:
- This hydraulic oil press machine is the most advanced equipment and takes up less area. Its material mainly electroplate.
- It is economic and environmental protection, stable and durable. This machine adopts automatic control system, hydraulic pressure control system and temperature control system.
- It has high pressure, high yield oil and easy to operate. This machine can work continuously for 24 hours. It can squeeze 4-23 kilogram per batch, the time of pressing is 8-15 minutes. The oil is pure and fragrant.
- The pressure of our machine is 60Mpa, higher than other machine(the normal is 45Mpa to 55Mpa), provide higher oil yield.
- The column material is military steel, very strong, extend the service life.
Detail:
Our service:
Service before sale
1.Professionally and patiently introduction, details pictures and working video to show machine.
2.Enter our factory to visit the machine and teach the machine operation method face to face.
3.Accept the raw materials sent by the customer for machine testing
Service on sale
1.Installation:quality and quantity guaranteed;completion of hand over.
2.Acceptance: acceptance test;accepted deliverables.
3.Technical training:on-site installation and products training;operation skills training;maintenance training;centralized technical training.
Service after sale
1.Technical service:long time technical service.
2.Accessories supplying:supplying spare parts with cost price.
3.24 hours online to solve any problem.
Delivery:
Our company's machines not only have a good market and reputation in China, but also have great sales and praise abroad.
