Automatic Alcohol Liquid Bottle Blow Moulding Processing Machine 15L Plastic
plastic processing machinery
Model No.: ABLB90(single station single die head)
ABLB90 auto plastic can making machine was specially designed for making plastic water tanks, plastic cans, lubricant oil bottles, plastic drums, plastic toys and other plastic containers not over 20L.
The features of this machine:
(1)It is suitable for producing PE,HDPE,PP, PVC so on,plastic containers and bottles in all shapes are available,the max.product volume is up to 20L.
(2)Single station single die head design,very easy to operate and maintenance.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Fully automatic process with low power consumption,high efficiency,quick and safe operation,easy for maintenance.
(5)Multiple screw available for double layer or tranparent liquid lever line.
(6)Auto deflashing device available,can remove the extra parts of bottles.
(7)Auto lubricant system controlled by PLC.
Technical Parameters: ( ABLB90 )
Max. Product volume | 20 liters |
Output capacity | 1680~1820pc/day |
Screw diameter | 90mm |
Screw L/D ratio | 25 L/D |
Screw drive power | 37KW |
Screw heating capacity | 18 KW |
No.of heating zone | 4 zones |
Output of HDPE | 130KG/H |
Oil pump drive power | 30 KW |
Clamping force | 260 KN |
Max.size of mold | 450-1000mm |
Mold stroke | 700 X 950mm |
Max.die diameter | 340mm |
Blowing pressure | 0.8 mpa |
Air Volume | 1 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 90 L/MIN |
Size of Machine | 4.4x2.6x3.1m |
Weight of machine | 9.3ton |
