Intelligent Q235 25m/Min 12t Agv Die Transport Cart
12 ton Intelligent Agv Die Transport Cart For Light Industrial
The 12ton intelligent agv die transport cart for light industrial (AGV), also commonly known as the AGV car, is equipped with automatic guiding devices such as electromagnetic or optical, inertial navigation, etc., which can travel along a prescribed guiding path and has safety protection. the intelligent agv die transport cart with various transfer functions, no need for the driver's van in industrial applications, and a rechargeable battery as the power source.
2019 China steerable battery powered material handling trackless electric transfer cart
With the expansion of the application field, the types and forms of AGVs become diverse. AGVs are often classified into the following types according to the navigation method during AGV automatic driving:
Compared with electromagnetic guidance, magnetic navigation uses magnetic strips on the road surface instead of embedding metal wires under the ground to realize navigation through magnetic induction signals. Flexibility is better, it is easier to change or expand the path, and the magnetic strip is easy to lay. The navigation method is mechanically damaged by hard objects such as metal passing through the loop, which has a certain influence on navigation.
The features as following:
- The agv transfer cart is battery powered, they represent the best solution for all those appliances with delicate handling problems in limited places.(360 degree turning flexibly)
- The agv trackless transfer cart is very flexible since it can move freely around the plant as indoor as outdoor.
- It is equipped with non-marking wheels to avoid any mark on floor.(Imported PU wheel or customized)
- Easy operation make transfer cart perfect to meet the most important requirements: where space is very limited and paths are strictly constrained.
Remark: Dimensions,capacity, loading platform superstructure, speed and many others features can be customized as per client request.
| Model | BWP-10t | BWP-20t | BWP-40t | BWP-60t | BWP-80t | BWP-100T | |
| Rated Load(t) | 10 | 20 | 40 | 60 | 80 | 100 | |
| Table size(mm) | Length(L) | 2300 | 2400 | 5000 | 5600 | 6500 | 6600 |
| Width(W) | 2000 | 2200 | 2500 | 2500 | 2800 | 3300 | |
| Height(H) | 550 | 600 | 800 | 850 | 950 | 1200 | |
| Wheel Base(mm) | 1650 | 1650 | 2000 | 1800 | 1950 | 2000 | |
| Axle Base(mm) | 1700 | 1850 | 3600 | 2900 | 3500 | 4000 | |
| Wheel Diameter(mm) | 350 | 400 | 500 | 600 | 600 | 600 | |
| Wheel Quantity(pcs) | 4 | 4 | 4 | 4 | 6 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 | 75 | |
| Running Speed(m/min) | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power(kw) | 2*2.2 | 2*3.5 | 2*6.3 | 2*10 | 30 | 40 | |
| Battery Capacity(Ah) | 250 | 330 | 440 | 600 | 800 | 1000 | |
| Battery Voltage(v) | 48 | 48 | 72 | 72 | 72 | 72 | |
| Max Wheel Load(kn) | 42.6 | 77.7 | 142.8 | 221.4 | 185 | 190 | |
| Reference Weight | 4.2 | 5.9 | 7.6 | 10.8 | 14.6 | 26.8 | |
