High Carbon Steel Sucker Rod Inserted Oilfield Pump Spray Metal Plunger
High Quality Oilfield Sucker Rod Inserted Pump
High quality oilfield sucker rod inserted pump description:
Rod pumps also are called insert pumps because they are run (inserted) in the production tubing.
Sucker rod pump is equipped with a seating nipple(there are two seating nipples in API-RHBM-AC) , seating nipple connection on the tubing string, down to the bottom of the well with the tubing string. Plunger assembly connection on the sucker rod string and with the pump overall down to seating nipple position together , pump with fixed inside the seating nipple , Plunger assembly with the sucker rod string up and down reciprocating movement to achieve pumping work.
There is a wide range of plunger (or pump-bore) sizes standardized by the industry. The API pump-bore sizes that are currently available range from 1 1/16 to 3 3/4 in. in diameter. This 1 1/16-in. size has been added back in the latest edition of the standard.
API parameters for RWBM model:
| Specification | Pump diameter (in) | Barrel length (ft) | Plunger length (ft) | Stroke length (ft) | Extension length (ft) | Tubing size EUE(in) |
| 20-125RWBM | Ø31.75 | 2.1-10.4 | 0.3-8.0 | 1.2-9.0 | 0.3-0.9 | 2-3/8” |
| 25-150RWBM | Ø38.10 | 2-7/8” | ||||
| 25-175RWBM | Ø44.45 | 2-7/8” | ||||
| 30-225RWBM | Ø57.15 | 3-1/2” |
Features
1. It is suitable for corrosion and small amount of sand and gas, deep Wells, such as complex well conditions.
2. The use of safe, stable performance and wide application. Under operation easy to operate, economical and practical, it can reduce oil field operation cost by more than 30%.
