API 11 AX RHAM Rod Heavy Wall Barrel with Spray Metal Plunger 25-175RHAM 20-2-2 Sucker Rod Pump
Price:
Negotiable
MOQ:
1 set
Delivery Time:
10~15 workdays
Brand:
Zhongshi
Product Description
API 11 AX RHAM Rod Heavy Wall Barrel with Spray Metal Plunger 25-175RHAM 20-2-2 Sucker Rod Pump
Product description
The pump body of the rod pump is inside the tubing string and is connected to the tubing string by a support joint.
Accessories name: N14-top mechanical locking support joint, G11-stem guide sleeve, S21-locking claw, C31-extended coupling, B12-pump, C14-pump closed valve cover, V11-valve pair, B22 - Valve cover reducer, B21 - stem reducer, R11 - stem, C12 - upper swim valve cover, P21 - male threaded plunger body, C13 - downstream dynamic valve cover, P12 - seat block plug.
Technical parameter list
| Specification | Pump diameter (in) | Barrel length (ft) | Plunger length (ft) | Stroke length (ft) | Extension length (ft) | Tubing size EUE(in) | Sucker rod size |
| 20-125RHAM | Ø1.25” | 2.1-10.4 | 0.3-8.0 | 1.2-9.0 | 0.3-0.9 | 2-3/8” |
CYJ16 CYJ19 |
| 25-150RHAM | Ø1.50 | 2-7/8” | |||||
| 25-175RHAM | Ø1.75” | 2-7/8” | |||||
| 30-225RHAM | Ø2.25” | 3-1/2” |
