High Efficiency Oilfield Pump Parts Anti Corrosion For Insert Pump 12 Months Warranty
High Efficiency Oilfield Pump Parts Anti Corrosion For Insert Pump 12 Months Warranty
Product Description
Pump barrel is one of the main part of the API sucker rod pump .
Pump barrel processing and material:
Pump barrel: plain carbon steel plating (A1), ordinary carbon steel carbonitriding (B1), ordinary carbon steel carburizing (B2), low alloy steel nitride (B5).
Features
1. Base on the technology of weatherford.
2. New and used rod all avaibable.
3. Anti-scaling.
4. Anti-corrosion.
Technical Specifications
|
Nominal diameter mm |
Length series of the plunger m |
Extension nipple length m |
O.D. of the connecting oil pipe mm |
Diameter of the connecting pumping rod mm |
Pump constant m3/d |
Max. O.D. mm |
| 28 |
0.6 0.9 1.2 1.5 |
0.3 0.6 0.9 |
60.3,73.0 | 16 | 0.916 | 88.9 |
| 32 | 60.3,73.0 | 16 | 1.140 | 88.9 | ||
| 38 | 60.3,73.0 | 16/19 | 1.642 | 88.9 | ||
| 44 | 60.3,73.0 | 19 | 2.235 | 88.9 | ||
| 57 | 73.0 | 19 | 3.694 | 88.9 | ||
| 70 | 88.9 | 22 | 5.518 | 107 | ||
| 83 | 101.6 | 22 | 7.707 | 114 | ||
| 95 | 114.3 | 25 | 10.261 | 121 |
