Round Type L80 Alloy Steel Tubing With Couplings For Transporting Oil Or Gas
Price:
Negotiable
MOQ:
1 metric ton
Delivery Time:
Negotiable
Brand:
Zhongshi
Product Description
Round Type L80 Alloy Steel Tubing With Couplings For Transporting Oil Or Gas
Description of oil tubing:
Tubing is the pipe used for transporting crude oil and natural gas from oil or gas layer to the surface
Description of oil tubing:
Tubing is the pipe used for transporting crude oil and natural gas from oil or gas layer to the surface
after drilling is complete.It is made to withstand the pressure generated from the extraction process.
Features:
1. Seamless pipe for oil well
2. Hot-rolled alloy steel pipe
Technical specification:
Features:
1. Seamless pipe for oil well
2. Hot-rolled alloy steel pipe
Technical specification:
|
Size Designation |
Weight Designation Lb/ft | Outside Diameter | Wall Thickness | |||
|
Nonupset T&C |
Ex-upset | In. | mm | In. | mm | |
| 2 3/8" | 4.00~7.35 | 4.70~7.45 | 2.375 | 60.33 | 0.167~0.336 | 4.24~8.53 |
| 2 7/8" | 6.40~11.50 | 6.50~9.45 | 2.875 | 73.03 | 0.217~0.440 | 5.51~11.18 |
| 3 1/2" | 7.70~17.00 | 9.30~12.95 | 3.5 | 88.9 | 0.216~0.530 | 5.49~13.46 |
| 4" | 9.50~22.20 | 11 | 4 | 101.6 | 0.226~0.610 | 5.74~15.49 |
| 4 1/2" | 12.60~26.10 | 12.75 | 4.5 | 114.3 | 0.271~0.630 | 6.88~16.00 |
Mechanical properties:
| Grade | Yield Strength | Tensile Strenght | Hardness | Allowable | |||||
| Min | Max | Min | Max | Max | Hardness | ||||
| Psi | Mpa | Psi | Mpa | Psi | Mpa | HRC | BHN | Variation | |
| J55 | 55,000 | 379 | 80,000 | 552 | 75,000 | 517 | - | - | - |
| K55 | 55,000 | 379 | 88,000 | 552 | 95,000 | 655 | - | - | - |
| N80 | 80,000 | 552 | 110,000 | 758 | 100,000 | 689 | - | - | - |
| N80-1 | 80,000 | 552 | 95,000 | 655 | 95,000 | 655 | 23 | 241 | - |
| C90 | 90,000 | 621 | 105,000 | 724 | 100,000 | 689 | 25.4 | 255 | 3 |
| C95 | 95,000 | 655 | 110,000 | 758 | 105,000 | 724 | - | - | - |
| T95 | 95,000 | 655 | 110,000 | 758 | 105,000 | 724 | 25.4 | 255 | 3 |
| P110 | 110,000 | 758 | 140,000 | 965 | 125,000 | 862 | - | - | - |
