Casing pipe description:
Casing pipe is most often used in underground construction projects to encase or protect utility lines
from being damaged.
Once a well has been drilled, if it is to become a production well, the well must undergo completion.
While drilling a well cuts through the rock formations and allows drilling engineers to reach the
reservoir below, the raw sides of the well cannot support themselves. Similar to the bones of your
spine protecting the spinal cord, casing is tubing that is set inside the drilled well to protect and support the wellstream.
Features:
1. Hot rolled seamless pipe
2. Size OD 4 1/2”-20”
Technical specifications:
| Grade : | J55,K55,N80,L80,P110 |
| Out Diameter: | 114.3-508mm |
| Wall Thickness: | 5.21-16.13mm |
| Length:: | 1-12meters |
| Standards: | API 5CT |
| Application: | Oilfield |
| Packing: | One side is coupling and the other side is thread protector |
| Delivery Time: | 7-20 days or depend on Quantity |
| Payment Terms: | 30%T/T deposit in advance ,the balance paid before shipment. or L/C at sight |
Mechanical properties:
| Standard | Grade | Tensile Strength(MPa) | Yield strength(MPa) | Elongation(%) | Hardness |
| API SPEC 5CT | J55 | ≥517 | 379~552 | According to API 5CT | |
| K55 | ≥655 | 379~552 | |||
| N80 | ≥689 | 552~758 | |||
| L80(13Cr) | ≥655 | 552~655 | ≤241HB | ||
| P110 | ≥862 | 758~965 |
