4 1/2 Inch Oilfield Tubing Pipe P110 Steel Grade 12.6# 12.75# Hot Rolled Seamless Pipe
Price:
Negotiable
MOQ:
1 metric ton
Delivery Time:
Negotiable
Brand:
Zhongshi
Product Description
4 1/2 Inch Oilfield Tubing Pipe P110 Steel Grade 12.6# And 12.75# With Special Packing
Description of oil tubing:
Tubing is used for transporting crude oil and natural gas from oil or gas layer to the surface,so this pipe
Description of oil tubing:
Tubing is used for transporting crude oil and natural gas from oil or gas layer to the surface,so this pipe
can bear the pressure generated from the extraction process. The usual for 4 1/2" tubing is 12.6# and
12.75#, the threads have EUE and NUE.
Features:
1. Hot rolled seamless pipe
Features:
1. Hot rolled seamless pipe
2. P110 steel grade
2. Production conform to API 5CT standard
2. Production conform to API 5CT standard
Technical specification:
| Specification | Weight code | Outside diameter (mm) | Wall thickness (mm) | Inner diameter (mm) | Calculated weight | ||||
| NUE(with thread and coupling) | EUE(with thread and coupling) | Plain end (kg/m) | Changed weight due to end process(kg) | ||||||
| Plain(with thread and coupling) | External upset threaded and coupled | ||||||||
| standard coupling | special coupling | ||||||||
| 1.9 | 2.75 | 2.9 | 48.26 | 3.68 | 40.9 | 4.05 | 0.27 | 0.91 | - |
| 2-3/8 | 4.6 | 4.7 | 60.32 | 4.83 | 50.66 | 6.61 | 0.73 | 1.81 | 1.34 |
| 2-7/8 | 6.4 | 6.5 | 73.02 | 5.51 | 62 | 9.17 | 1.45 | 2.54 | 1.71 |
| 2-7/8 | 8.6 | 8.7 | 73.02 | 7.82 | 57.38 | 12.57 | 1.18 | 2.27 | 1.43 |
| 3-1/2 | 9.2 | 9.3 | 88.9 | 6.45 | 76 | 13.12 | 2.27 | 4.17 | 2.45 |
| 3-1/2 | 12.7 | 12.95 | 88.9 | 9.52 | 69.86 | 18.64 | 1.81 | 3.72 | 2 |
| 4 | 10.7 | 11 | 101.6 | 6.65 | 88.3 | 15.57 | - | 4.81 | - |
| 4-1/2 | 12.6 | 12.75 | 114.3 | 6.88 | 100.54 | 18.23 | 2.72 | - | - |
Mechanical Properties:
| Standard | Steel grade | Tensil Strength(Mpa) | Yeild Strength(Mpa) | Elongation(%) |
| API 5CT | J55 | ≥517 | 379~552 | 0.5% |
| API 5CT | K55 | ≥655 | 379~552 | 0.5% |
| API 5CT | N80 | ≥689 | 552~758 | 0.5% |
| API 5CT | L80 | ≥655 | 552~655 | 0.5% |
| API 5CT | P110 | ≥862 | 758~965 | 0.6% |
