N80Q Steel Grade Oilfield Tubing Pipe PSL1 In API Packed By Packing Frame
Price:
Negotiable
MOQ:
1 metric ton
Delivery Time:
Negotiable
Brand:
Zhongshi
Product Description
N80Q Steel Grade Oilfield Tubing Pipe PSL1 In API Packed By Packing Frame
13Cr tubing description:
Tubing pipe is mounted in the production casing after the oil well is dig and cemented. It is a seamless
pipe which transport oil and gas to the ground.
13Cr tubing pipe not only has a higher strength and excellent corrosion resistant properties, but also
has good low temperature toughness.
Features:
1. Alloy steel pipe
2. For general well conditions and acid well conditions
Technical specification:
| Size | Nominal Weight | OD (mm) | Wall thickness (mm) | ID (mm) | Calculated weight | ||||
| NUE(with thread and coupling) | EUE(with thread and coupling) | Plain end (kg/m) | Changed weight due to end process(kg) | ||||||
| Plain(with thread and coupling) | External upset threaded and coupled | ||||||||
| standard coupling | special coupling | ||||||||
| 1.9 | 2.75 | 2.9 | 48.26 | 3.68 | 40.9 | 4.05 | 0.27 | 0.91 | - |
| 2-3/8 | 4.6 | 4.7 | 60.32 | 4.83 | 50.66 | 6.61 | 0.73 | 1.81 | 1.34 |
| 2-7/8 | 6.4 | 6.5 | 73.02 | 5.51 | 62 | 9.17 | 1.45 | 2.54 | 1.71 |
| 2-7/8 | 8.6 | 8.7 | 73.02 | 7.82 | 57.38 | 12.57 | 1.18 | 2.27 | 1.43 |
| 3-1/2 | 9.2 | 9.3 | 88.9 | 6.45 | 76 | 13.12 | 2.27 | 4.17 | 2.45 |
| 3-1/2 | 12.7 | 12.95 | 88.9 | 9.52 | 69.86 | 18.64 | 1.81 | 3.72 | 2 |
| 4 | 10.7 | 11 | 101.6 | 6.65 | 88.3 | 15.57 | - | 4.81 | - |
| 4-1/2 | 12.6 | 12.75 | 114.3 | 6.88 | 100.54 | 18.23 | 2.72 | - | - |
Mechanical properties:
| Steel Grade | Yield Strength Ksi(Mpa) |
Mild tensile Ksi(Mpa) |
Elongation | hardness (HRC) | |
| Min | Max | Min | Max | ||
| L80-13cr | 80 (552) | 95 (655) | 95 (655) | API5CT | 23 |
| C95-SP13Cr1 C95-SP13Cr2 |
95 (655) | 110 (758) | 110 (724) | 30 | |
| p110-Sp13Cr1 p110-Sp13Cr2 |
110 (758) | 140 (965) | 125 (862) | 33 | |
