API Reamer Shoe Oil Well Drilling Equipment Forging High Manganese Steel Material
Price:
Negotiable
MOQ:
1
Delivery Time:
depends on quantity
Brand:
Puyang Zhongshi Group
Product Description
Drilling Tool API reamer shoe for oil well
Reamer shoes overcome wellbore obstructions and guide the casing or liner to total depth. Our reamer shoe designs use an eccentric guide nose to negotiate ledges and other obstructions while its integrated cutting structures simultaneously ream out tight spots.
Features
- Easy drill out with PDC bits;
- Material: P-110, K55, J55, N80
- Withstands long periods of circulation;
- Automatic fill-up, saves considerable running-in time of casing;
- High strength design ensures high pressure bump and back flow resistance;
- Special non-rotational groove design ensures cementing plugs dilled out quickly;
Specification
| Size (in) | Min.Bore parameter(in) | Bore O.D(in) | Bore ID(in) | Thread type | Ib(in2 | |
| Float collar | 5 1/2” | 2” | 6” | 4 3/4” | 5 1/2” LCSG | 4351 |
| 7” | 2 3/8” | 7 5/8” | 6 1/4” | 7”LCSG | 3626 | |
| 9 5/8” | 2 3/8 | 10 5/8” | 8 5/8” | 9 5/8” LCSG | 3626 | |
| 13 3/8” | 2 3/8 | 14 3/8” | 12 3/8” | 13 3/8” LCSG | 3626 | |
| Float shoe | 5 1/2” | 2” | 6” | 4 3/4” | 5 1/2” LCSG | 4351 |
| 7” | 2 3/8 | 7 5/8” | 6 1/4” | 7”LCSG | 3626 | |
| 9 5/8” | 2 3/8 | 10 5/8” | 8 5/8” | 9 5/8” LCSG | 3626 | |
| 13 3/8” | 2 3/8 | 14 3/8” | 12 3/8” | 13 3/8” LCSG | 3626 | |
