All Grade Alloy Steel Oil Field Rods Welding Hollow With Api 11b Customized Length
High Strength API 11B Polished Pony Oilfield Sucker Rods 5 / 8 " AISI 4330 Alloy Steel with Rod Coupling
Products Description:
sucker rod is the common equipment in the oil extraction. It is manufactured through many process including the testing, straightening and forging. The sucker rod is placed between the polished rod and oil well pump. To deliver power. Sucker rod is manufactured from high quality carbon steel and alloy steel, which is conform to the API Spec 11B standard. Sucker rod has various types including the common sucker rod, hollow sucker rod and FRP sucker rod. Comamonly we use the sucker rod coupling to connect the sucker rod. The sucker rod also has various specs to fit.
Features:
1. C grade sucker rod series - is mainly used for light, medium load, no corrosion or corrosion shallow Wells or in deep well pumping, material is carbon steel or manganese steel.
2. Grade D sucker rod is made of high quality alloy steel, after heat treatment with high strength, plasticity is good, long life and other characteristics, it is suitable for light when there is no corrosion or corrosive medium in the deep Wells under the environment of use.
3. K level of sucker rod with different content of Ni Cr - Ni - Mo high quality alloy steel manufacturing, have anticorrosive, resistance to corrosion function, respectively applicable to strong corrosion of shallow, middle and deep Wells.
Mechanical Properties of Sucker Rods:
| No. | Grade | Tensile Strength Rel(Mpa) |
Yield Strength Rm(Mpa) |
Percentage Elongation A(%) | Contraction Percentage Of Area Z(%) |
| 1 | C | 620-795 | ≥415 | ≥13 | ≥50 |
| 2 | K | 620-795 | ≥415 | ≥13 | ≥60 |
| 3 | D | 795-965 | ≥590 | ≥10 | ≥50 |
| 4 | KD | 795-965 | ≥590 | ≥10 | ≥50 |
| 5 | HL | 965-1195 | ≥795 | ≥10 | ≥45 |
| 6 | HY | 965-1195 | —— | —— | —— |
Sucker rod Size:
| SIZE (in) |
ROD D.(in) | THREAD D. (in) |
LENGTH (ft) |
OUTSIDE DIAMETER OF PIN SHOULDER(mm) |
LENGTH OF PIN(mm) |
LENGTH OF WRENCH SQUARE(mm) |
WIDTH OF WRENCH SQUARE(mm) |
| 5/8" | 5/8" | 15/16 | 2 4 6 8 10 25 30 |
31.75 | 31.75 | ≥31.75 | 22.23 |
| 3/4" | 3/4" | 1-1/16 | 38.10 | 36.51 | 25.40 | ||
| 7/8" | 7/8" | 1-3/16 | 41.28 | 41.28 | |||
| 1" | 1" | 1-3/8 | 50.80 | 47.63 | ≥38.10 | 33.34 | |
| 1-1/8" | 1-1/8" | 1-9/16 | 57.15 | 53.98 | ≥41.28 | 38.10 |
