Oil Painting Surface Oilfield Tubing Pipe With Length R2 Hot Rolled Processing

Price Negotiable

Price: Negotiable

MOQ: 1 metric ton

Delivery Time: Negotiable

Brand: Zhongshi

Product Description

Seamless Oilfield Tubing Pipe With Length R2 For Oil Production Function

Oil tubing description:

Tubing is pipe used for the transportation of crude oil and natural gas from an oil or gas layer

to the surface after drilling is complete. It is made to withstand the pressure generated from

the extraction process. Tubing is manufactured in the same way as casing, except that an

additional process known as "upsetting" is applied to thicken the pipes.

Features:

1. Specification range:OD: 42.16 MM - 114.3 MM(1.66"--4 1/2") WT:3.56-16mm(2.3ppf-26.1ppf)

2. Materials: H40, J55, K55, N80-1, N80-Q, L80-1,L80-9Cr, L80-13Cr, P110, Q125 etc

3. Executive standards: API 5CT, GB, ISO11960, GOST

4. Thread connection: NU, EU,IJ

5. Length: R1, R2, R3

6. Testing: NDT etc related rules of API 5CT and 5B

7:Type:seamless pipe

Technical specification:

Standard		API 5CT/ ISO11960
Grade	Group.1	H40/PSL.1, J55/PSL.1, J55/PSL.2, J55/PSL.3, K55/PSL.1, K55/PSL.2, K55/PSL.3,
		N80(1)/PSL.1, N80(1)/PSL.2, N80(Q)/PSL.1, N80(Q)/PSL.2, N80(Q)/PSL.3
	Group.2	M65/PSL.1, M65/PSL.3, L80/PSL.2, L80(1)/PSL.1, L80(1)/PSL.3, L80(9Cr)/PSL.1, L80(13Cr)/PSL.1, C90/PSL.1, C90/PSL.2, C90/PSL.3, T95/PSL.1, T95/PSL.2T95/PSL.3
	Group.3	P110/PSL.1, P110/PSL.2, P110/PSL.3,
	Group.4	Q125/PSL.1, Q125/PSL.2, Q125/PSL.3,
OD	Tubing	1.66 inch to 4 1/2 inch or 42.16mm to 114.3mm
	Casing	4 1/2 inch to 20 inch or 114.3mm to 508mm
Wall Thickness		According to API 5CT Standard
Length	Tubing	R1 (6.10m to 7.32m), R2 (8.53m to 9.75m), R3 (11.58m to 12.80m)
	Casing	R1 (4.88m to 7.62m), R2 (7.62m to 10.36m), R3 (10.36m to 14.63m)
Type		Seamless
End-Finish	Tubing	P, I, N, U
	Casing	P, S, B, L
