3 1/2" Spray Metal Plunger Oilfield RHBM Sucker Rod Pump

Oil Production RHBM Model Sucker Rod Pump

Sucker rod pump description:

Sucker rod pump is equipped with a seating nipple(there are two seating nipples in API-RHBM-AC) , seating nipple connection on the tubing string, down to the bottom of the well with the tubing string. Plunger assembly connection on the sucker rod string and with the pump overall down to seating nipple position together , sucker rod pump with fixed inside the seating nipple , Plunger assembly with the sucker rod string up and down reciprocating movement to achieve pumping work.
if the sucker rod pump appeared quality problem, need not put forward the tubing string, only need put the whole pump forward well through the sucker rod string together , operation is simple

API-RHBM, Rod, Stationary Heavy Wall Barrel, Mechanical Bottom Anchor Pump it can reduce oil field operation cost by more than 50%.

Features

1. API 11AX standard oil production pumps

2. Good corrosion resistant effect

3. Easy to operate

4. It can be designed according to the customer’s well

Technical parameter list
