API 11AX Series Sucker Rod Pump Downhole Pumps Oil And Gas
Oil Well Down Hole API 11AX Series Sucker Rod Pump
Down Hole Sucker Rod Pump Description
A Sucker Rod Pump is an artificial pump system used to connect the downhole pump assembly with the surface components that facilitate a pumping motion. This pump system uses different types of components that generate reciprocating motions which make it easy to lift fluids from bottom to the surface in a vertical movement. It is powered by a motor that causes the plunger to work in two strokes, i.e., up and down.
The main components of a sucker rod pump are standing and traveling valves, plunger, barrel, seating assembly, pull tube or valve rod.
Technical parameter list:
| Model | Pump diameter (in) | Barrel length (ft) | Plunger length (ft) | Stroke length (ft) | Extension length (ft) | Tubing size EUE(in) |
| 25-175RWAM | Ø50.8 | 2.1-10 | 0.3-8.0 | 1.2-9.0 | / | 3-1/2" |
| 25-175RWAC | ||||||
| 30-225RWBM | Ø63.5 | |||||
| 30-225RWBC |
Features
1. Sucker rod type downhole pump, not tubing pump
2. Mechanical seating and cup seating
3. Heavy wall barrel and thin wall barrel
Mechanical Propertie
Heaby wall barrel pump is stronger than the thin wall barrel pump
