25-225 API 11AX Oil Well Tubing Pump Large Flowing Area
25-225 API 11AX THM Type Oil Well Tubing Pump
API 11AX tubing pump description:
For some large production wells, larger bore of tubing pump can be worked if the on-off connector is installed. Tubing pump is the strongest pump. It has large flowing area for fluid and it is suitable for producing viscosity oil.
Stationary Heavy Wall, Tubing Pump, its standing valve can not be pulled out.
The pump barrel assembly of the tubing pump connected on the tubing string,and with its down to the bottom of the well.Plunger assembly connected on the sucker rod string and with it down to the pump barrel position in the well,then with it do up and down reciprocating motion, so as to realize the production process.
API Tubing pump models: THBM and THBC
Features
1. Large flowing area for fluid.
2. Be suitable for producing viscosity oil
Tubing pump technical parameters:
| Model | pump diameter(in) | Barrel length(ft) | Plunger length(ft) | stroke length(ft) |
Tubing size EUE(in) |
| 20-175THM | Ø44.45 | 7-34 | 1-26 | 4-29 | 2 3/8" |
| 25-225THM | Ø57.15 | 2 7/8" | |||
| 30-275THM | Ø69.85 | 3 1/2" | |||
| 40-375THM | Ø95.25 | 4 1/2" |
