3/4 Oilfield Sucker Rods Wheeled Rod Guides 6.5ppf N80 Tubing API
Price:
Negotiable
MOQ:
1
Delivery Time:
2weeks
Brand:
Zhongshi
Product Description
API Wheeled Rod Guides for 3/4 Sucker Rods & 2-7/8 6.5ppf N80 Tubing
Products Description:
1) On the first two or three rods above the bottom hole pump.
2) Intermittently throughout the rod string where wear is indicated on rods or tubing.
3) Where known hole deviation occurs.
4) On the first two or three rods below the stuffing box.
Tech Parameter
| Specification | DIMENSIONS(INCH) | ||
| Diameter | Length | Length of the groove | |
| 5/8''ROD/2-3/8''TUBING | 1.50 | 27 | 1.80 |
| 3/4''ROD/2-3/8''TUBING | 1.50 | 27 | 1.80 |
| 5/8''ROD/2-7/8''TUBING | 1.50 | 27 | 2.25 |
| 3/4''ROD/2-7/8''TUBING | 1.50 | 27 | 2.28 |
| 7/8''ROD/2-7/8''TUBING | 1.625 | 27 | 2.28 |
| 1''ROD/2-7/8''TUBING | 2.0 | 29 | 2.28 |
| 3/4''ROD/3-1/2''TUBING | 1.50 | 31 | 2.75 |
| 7/8''ROD/3-12''TUBING | 1.625 | 31 | 2.75 |
| 1''ROD/3-1/2''TUBING | 2.0 | 31 | 2.75 |
